Control parts
TCD 2013 2VW 11-01-01
Technical Data
Testing and setting data
Tightening specifications
ID no. Name Additional information Value
P01 61 Valve clearance (inlet) with rotary angle disc 90°
P01 62 Valve clearance (outlet) with rotary angle disc 150°
ID no. Name Screw type Notes / Remark Value
A01 003
Locking nut,
valve clearance setting screw
20 Nm
A01 012
Locking nut, setting screw control pis
-
ton (exhaust gas return)
20 Nm
For the tightening procedure according to torque using a torque wrench, a maximum variation of the
tightening torque of +/- 10% is permissible.
