33
Product Guide ineo
163/213
Section CM Parts Time
Paper Size Detection SW 06:00 sec.
PWB-I (Paper Size Detection Board) 04:37 sec.
Operation Panel 01:22 sec.
CCD Unit 04:29 sec.
Exposure Lamp 06:54 sec.
Exposure Lamp Inverter 06:38 sec.
Original Size Detection Sensor 02:34 sec.
ATDC Sensor 01:14 sec.
Upper Fusing Roller 12:21 sec.
Lower Fusing Roller 29:29 sec.
Thermistor 25:02 sec
Fusing Section JAM Detection Sensor 29:51 sec.
Main Body
Thermostat 11:03 sec.
Paper Size Detection Sensor 09:32 sec.
Bypass Feed
Pick-up Drive Solenoid 07:43 sec.
JAM Sensor 04:32 sec.
Duplex PWB 02:15 sec.
Duplex Unit
Duplex Drive Motor 01:40 sec.
Main PWB 05:10 sec.
Cooling Fan Motor (M3) 04:26 sec.
PC7 (Upper Cover Sensor) 01:40 sec.
PC5 (Original Empty Sensor 01:29 sec.
PC6 (Separator Sensor) 02:00 sec.
DF-502
PBA-SIZE (Mixed Original Detection Board) 01:50 sec.
Section CM Parts Time
SL1-ADF (Exit Separation SL) 02:00 sec.
PBA-LED 01:42 sec.
PBA-VR (Original Size Detection VR [width direction]) 10:22 sec.
PC2 (Original Size Detection Sensor 2) 05:53 sec.
PC1 (Original Size Detection Sensor 1) 05:40 sec.
PC3 (Original Size Detection Sensor 3) 05:40 sec.
PC4 (Original Size Detection Sensor 4) 05:40 sec.
M1-ADF (Pick-up Drive Motor) 14:58 sec.
M2-ADF (Transportation Motor) 13:53 sec.
PC8 (Original Detection Sensor) 24:21 sec.
PC9 (Resist Sensor) 23:41 sec.
DF-502
PC10 (Exit Sensor) 23:41 sec.
Main Motor 01:54 sec.
Main PWB 02:19 sec.
Pick-up Drive Clutch 03:16 sec.
Original Empty Sensor 03:59 sec.
Resist Sensor 03:59 sec.
Separator Sensor 03:59 sec.
Exit Sensor 03:59 sec.
Original Size Detection Sensor (Long Direction) 03:27 sec.
DF-605
Original Size Detection Sensor (Width Direction) 05:02 sec.
