3. Mount and reassemble the thermostat.
The thermostat is to be installed in a flush-mounting
box or a surface-mounting box for the FUGA design.
▪
Put the unit back in place and tighten the screws in
each side to fasten the thermostat.
▪
Press the front cover back in place.
4. Turn on the power supply.
3 Settings
Please be aware of the following:
▪
The floor temperature is measured where the sensor is
placed.
▪
The temperature of the bottom of a wooden floor can
be up to 10 degrees higher than the top.
▪
Floor manufactures often specify the max temperature
on the top surface of the floor (usually 27-28˚C).
▪
Always use a floor sensor to control floor heating.
DEVIreg™ 233
Installation Guide 9
