EN
P1=
P2=
P3=
P1= 1/8" G
P2= 1/8" G
P3= 1/8" G
DIMENSIONS WITH MANIFOLD
FUNCTIONAL DESCRIPTION
SPECIFICATIONS
MANIFOLD CONNECTIONS
L x H x W mm
WEIGHT WITH MANIFOLD
127 x 97 x 44 127 x 64 x 89
7 Bar [102 psi]
7 Bar [102 psi]
Max Air Input Pressure
Max Fluid Input Pressure
Cylinder Air Pressure 4 - 7 Bar [58 psi - 102 psi]
40°C Nominal [104°F]Max Ambient Operating Temperature
Electroless Nickel Plated Brass
Gun Body Material
Air Cap Material
Fluid Tip and Needle Construction
Stainless Steel
Stainless Steel
Nitride Coated Stainless Steel
Fluid Inlet Size
Cylinder Inlet
Seals and O-Rings HDPE, Viton Extreme
LEVER TYPE
LEVER TYPE
LEVER TYPE
SCREW TYPE
SCREW TYPE
SCREW TYPE
1/4" G
1/4" NPS
1/8" G
940g 850g
Quickclean™ Coated Aluminium
WEIGHT
The AG362 low pressure air atomising spray guns are designed to be fast changeover, modular
construction applicators, for spray finishing on machines and fixed mountings.
The AG362 can be mounted on either a rear entry, lever operated, fast detachable manifold, or a
screw attached, low profile manifold, dependant on the part number selected and mounting
preference.
The AG362 is intended for most types of general industrial coating and fine finishing operations,
suitable for both water based and solvent based applications.
Guns are available with a range of Conventional, Trans-Tech (High Efficiency) and HVLP atomisation
air caps, to give a choice of atomisation and Transfer Efficiency parameters.
The gun is designed as a flexible solution for the modern coating applicator, with multiple accessories
available, to further optimise the process.
FLUID AND AIR INLET PRESSURES
ENVIRONMENTAL
MATERIALS OF CONSTRUCTION
Gun Head and Fluid Passageways
Air Inlet Size
SB-E-2-643 R5.0
2/28
