EN
1
2
3
4
P2
Fluid reservoir
NOTE
Fluid filter
Fluid supply
Fluid restrictor valve
Protective coatings have been used for storage protection. Flush the equipment fluid passageways
with appropriate solvent before use.
Fluid - 1/4" G
TYPICAL FLUID CONNECTION SCHEMATIC
3
1
4
2
P2
P2
SB-E-2-642 R3.1
9/24
