DeVilbiss JGA Series - Parts List

4
© 2007 ITW Finishing Systems and Products
Parts List
Ref. No Description Part Number Qty
1 Air Cap/Retaining ring See Chart 2 1
1a Spring Clip - Kit of 5 JGA-156-K5 1
+2 Nozzle See Chart 3 1
3 Baffle + Seal JGD-402-K 1
+3a Baffle seal—Kit of 5 GTI-33-K5 1
+4 Spring Adjusted Needle Packing GTI-445-K2 1
5 Spreader Valve GTI-405-K 1
6 Stud and Screw - Kit of 5 GTI-408-K5 1
+7 Needle See Chart 3 1
+8 Spring - Kit of 5 GTI-409-K5 1
9 Bushing JGA-17 1
10 Needle Adjusting Screw GTI-414-K 1
11 Valve Assembly JGK-449 1
12 Trigger GTI-108 1
13 Connector JGA-158 1
14 Airflow Valve GTI-415-K 1
15 Lock Nut - Kit of 5 JGA-51-K5 1
16 Seal 23165-001 1
17 Fluid Inlet Connector and seal Kit JGA-159-K 1
18 Seal + Pin kit ( + SST-8434-K5) GTI-428-K5 2
19 Circlip - Kit of 5 2
20 Circlip - Kit of 5 25746-007-K5 1
+21 Seal - Kit of 5 JGS-72-K5 2
22 Air valve stem assembly 1
23 Spring JGV-262-K5 1
+ - Parts included in service Kit KK-4502 (see accessories)
E
E
No Order No.
G
0.7
FX
1.1
FZ
1.2
FF
1.4
FW
1.6
EE
1.8
EX
1.8
DE
2.0
D
2.2
AC
2.8
Air-
flow
Pressure
bar
30+ AV-4239-30
9 9 9
301 3.0
43 AV-4239-43
9 9
307 3.0
62 MB-4039-62
9
449 3.0
64 MB-4039-64
9
432 3.0
78 MB-4039-78
9 9
457 3.0
80 MB-4039-80
9
311 3.0
186 AV-4239-186
9 9
344 3.0
704 AV-4239-704
9
418 3.0
765 AV-4239-765
9 9 9
476 3.0
777 AV-4239-777
9 9
462 3.0
797 AV-4239-797
9 9 9 9
463 3.0
Aircap number and Nozzle size combinations Chart 2
