Appendix 34
devolo Magic 2 LANtriple
5 Appendix
5.1 Technical specifications
5.2 Bandwidth optimization
To significantly improve the transmission capacity
of the network, we recommend that you comply
with the following "connection rules":
b Plug the devolo Magic 2 LAN triple directly into
a wall socket. Avoid using power strips. This
may impair the transmission of the PLC signals.
b If there are several sockets in the wall directly
next to each other, they behave like a power
strip. Individual sockets are optimal.
Security 128 Bit AES
Device port 3x RJ45
(Gigabit Ethernet port)
Power consumption Maximum: 5.9 W
Typical: 5.0 W
Stand-by: 30.9 W
Power supply internal
196-250 V AC
50 Hz
Temperature
(Storage/Operating)
-25°C to 70 °C / 0°C to
40°C
Dimensions
(in mm, without plug)
143x72x41 (HxWxD)
Ambient conditions 10-90% Humidity,
non-condensing
Certifications CE
Fig. 3: Bandwith optimization
