19 Installation
devolo WiFi pro 1750e
햵 Screw in the holder onto the WiFi pro 1750e
handtight using the provided (shorter) screws.
햶 Now, place the WiFi pro 1750e with the antennas
pointing downward onto the screw heads in the
wall along with the holder.
The ventilation slots on the top side
of the WiFi pro 1750e must not be
covered. Sufficient ventilation must
be ensured!
3.3.1 Connecting the WiFi pro 1750e
햷 Switch the WiFi pro 1750e on using the On/Off
switch.
To prevent damage to the device, the
WiFi pro 1750e is supplied with po-
wer either only using the 12 V DC IN
connection or using the LAN 1 (PoE)
connection.
햸 Finally, to supply the WiFi pro 1750e with power:
쑗 either plug the barrel connector for the
mains adapter into the 12 V DC power
connection on the WiFi pro 1750e and plug
the mains adapter into a wall socket
쑗 or use a PoE cable to connect the LAN 1
(PoE) connection of the WiFi pro 1750e to
the PoE connection of a device supplying
power.
To disconnect the device from the
mains supply, unplug the device from
the wall socket or remove the PoE ca-
ble if the PoE supply is being used.
The power socket and all connected
network cables should be easily ac-
cessible so that you can pull out the
mains plug quickly if needed.
햹 If you would like to connect the WiFi pro 1750e to
your Internet router over Ethernet, connect both
devices using an Ethernet cable.
햺 You can find more information on configuring
your WiFi pro 1750e in Chapter 4 Network con-
figuration.
