ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.
WARNING! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or seriousinjury.
WARNING: To reduce the risk of injury, read
the instructionmanual.
If you have any questions or comments about
this or any
DeWALT
tool, call us toll free at:
1-800-4-
DeWALT
(1-800-433-9258).
1
Trigger
2
Trigger lock-off
3
Power Selection Switch
4
Utility hook
5
Contact trip release lever
6
Contact trip
7
Removable top stand
8
Stall release lever
9
Low battery & jam/stall
indicator lights (x2)
10
Battery pack
11
Battery release button
12
Magazine
13
Magazine support leg
14
Magazine release lever
15
Pusher
Fig. A
1
2
5
6
7
8
9
10
11
12
13
14
15
4
3
