ENGLISH
7
1 Keyless chuck (D25144)
1 Instruction manual
• Check for damage to the tool, parts or
accessories which may have occurred during
transport.
• Take the time to thoroughly read and
understand this manual prior to operation.
Description (fig. 1, 5, 8)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury could result.
a. Variable speed switch
b. Main handle
c. Forward/Reverse lever
d. Mode selector
e. Mode selector button
f. SDS Plus tool holder
g. Depth adjustment rod
h. Side handle
i. Depth rod button
j. Sleeve
k. Dust cover
l. Date code
m. Locking collar (D25144)
n. Keyless chuck (D25134/D25144)
o. Lock-on button
INTENDED USE
The D25032 heavy-duty rotary hammer has been
designed for professional drilling, hammerdrilling, and
screwdriving. The D25033, D25133 and D25144
heavy-duty rotary hammers have been designed for
professional drilling, hammerdrilling, screwdriving and
light chipping.
DO NOT use under wet conditions or in presence of
flammable liquids or gases.
These hammerdrills are professional power tools.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
• Young children and the infirm. This appliance
is not intended for use by young children or
infirm persons without supervision.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone with
this product.
Torque Limiting Clutch
All rotary hammerdrills are equipped with a torque
limiting clutch that reduces the maximum torque
reaction transmitted to the operator in case of
jamming of a drill bit. This feature also prevents the
gearing and electric motor from stalling. The torque
limiting clutch has been factory-set and cannot be
adjusted.
Electrical Safety
The electric motor has been designed for one
voltage only. Always check that the power supply
corresponds to the voltage on the rating plate.
Your DeWALT tool is double insulated in
accordance with IEC 60745; therefore no
earth wire is required.
WARNING: 115 V units have to
be operated via a fail-safe isolating
transformer with an earth screen
between the primary and secondary
winding.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
DeWALT service organisation.
Using an Extension Cable
If an extension cable is required, use an approved 3–
core extension cable suitable for the power input of
this tool (see technical data).The minimum conductor
size is 1.5 mm
2
; the maximum length is 30 m.
When using a cable reel, always unwind the cable
completely.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of
injury, turn unit off and disconnect
machine from power source before
installing and removing accessories,
before adjusting or changing set-
ups or when making repairs. Be sure
the trigger switch is in the OFF position.
An accidental start-up can cause injury.
Selecting the Operating Mode
(fig. 2)
The tool can be used in the following operating
modes:
Rotary drilling: for screwdriving and for
drilling into steel, wood and plastics
