8
ENGLISH
These hammerdrills are professional power tools.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
• Young children and the infirm. This appliance
is not intended for use by young children or
infirm persons without supervision.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone with
this product.
Torque Limiting Clutch
All rotary hammerdrills are equipped with a torque
limiting clutch that reduces the maximum torque
reaction transmitted to the operator in case of
jamming of a drill bit. This feature also prevents the
gearing and electric motor from stalling. The torque
limiting clutch has been factory-set and cannot be
adjusted.
Electrical Safety
The electric motor has been designed for one
voltage only. Always check that the power supply
corresponds to the voltage on the rating plate.
Your DEWALT tool is double insulated in
accordance with EN 60745; therefore no
earth wire is required.
WARNING: 115 V units have to
be operated via a fail-safe isolating
transformer with an earth screen
between the primary and secondary
winding.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
D
EWALT service organisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the old plug.
• Connect the brown lead to the live terminal in
the plug.
• Connect the blue lead to the neutral terminal.
WARNING: No connection is to be
made to the earth terminal.
Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 13 A.
Package Contents
The package contains:
1 Heavy-duty rotary hammerdrill
1 Side handle
1 Depth adjustment rod
1 Kitbox
1 Keyless chuck (D25134, D25144)
1 Instruction manual
• Check for damage to the tool, parts or
accessories which may have occurred during
transport.
• Take the time to thoroughly read and
understand this manual prior to operation.
Description (fi g. 1, 5, 8)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury could result.
a. Variable speed switch
b. Main handle
c. Forward/Reverse lever
d. Mode selector
e. Mode selector button
f. SDS Plus tool holder
g. Depth adjustment rod
h. Side handle
i. Depth rod button
j. Sleeve
k. Dust cover
l. Date code
m. Locking collar (D25134/D25144)
n. Keyless chuck (D25134/D25144)
o. Side handle work light (D25144/D25263)
p. Battery door screw (D25144/D25263)
q. On/off light button (D25144/D25263)
INTENDED USE
The D25032 heavy-duty rotary hammer has been
designed for professional drilling, hammerdrilling,
and screwdriving. The D25033, D25133, D25134,
D25144 and D25263 heavy-duty rotary hammers
have been designed for professional drilling,
hammerdrilling, screwdriving and light chipping.
DO NOT use under wet conditions or in presence of
flammable liquids or gases.
