Protecting the Environment
w
Separate collection. Products marked with this symbol
must not be disposed of with normal householdwaste.
Products contain materials that can be recovered or
recycled, reducing the demand for raw materials. Please
recycle electrical products according to local provisions. Further
information is available at www.2helpU.com.
Optional Accessories

WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Various types of SDSmax® drill bits and chisels are available as
anoption. Accessories and attachments used must be regularly
lubricated around the SDSmax®fitment.
Consult your dealer for further information on the
appropriateaccessories.
D
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
C
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
Drilling with a Core Bit (Fig.A, B)
1. Insert the appropriate corebit.
2. Assemble the centerdrill into the corebit.
3. Set the mode selector switch
3
to the rotary
hammerdrillingposition.
4. Turn the electronic speed and impact control dial
8
to a
medium or high speedsetting.
5. Fit and adjust the side handle
13
.
6. Place the centerdrill on the spot and switch on the tool. Drill
until the core penetrates into the concrete approximately
1cm.
7. Stop the tool and remove the centerdrill. Place the core bit
back into the hole and continuedrilling.
8. When drilling through a structure thicker than the depth of
the core bit, break away the round cylinder of concrete or
core inside the bit at regularintervals.
To avoid unwanted breaking away of concrete around
the hole, first drill a hole the diameter of the centerdrill
completely through the structure. Then drill the cored hole
halfway from eachside.
9. Always turn the tool off when work is finished and
beforeunplugging.
Chipping and Chiselling (Fig.A, B)
1. Insert the appropriate chisel and rotate it by hand to
lock it into one of 24positions. Refer to Indexing the
ChiselPosition.
2. Set the mode selector switch
3
to the 'hammering
only'position.
3. Set the electronic speed and impact control dial
8
.
4. Fit and adjust the side handle
13
.
5. Turn the tool on and startworking.
6. Always turn the tool off when work is finished and
beforeunplugging.
Recommendations for Tool Operation
• When drilling, always apply pressure in a straight line with
the bit, but do not push hard enough to stall the motor or
deflect thebit. A smooth even flow of material indicates the
proper drillingrate.
• If drilling thin material or material that is prone to splinter,
use a wood “back-up” block to prevent damage to
theworkpiece.

WARNING:
• Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol,etc.).
• Do not mix or stir inflammable liquids
labelledaccordingly.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
