19
EngLIsH
ʵ Watch what you are doing. Use common sense. Do not operate the tool when you are
tired or under the influence of drugs oralcohol.
20 . Check for damagedparts.
ʵ Before use, carefully check the tool and mains cable to determine that it will operate
properly and perform its intended function. Check for alignment of moving parts, binding
of moving parts, breakage of parts, mounting and any other conditions that may affect its
operation. A guard or other part that is damaged should be properly repaired or replaced
by an authorized service centre unless otherwise indicated in this instruction manual.
Have defective switches replaced by an authorized service centre. Do not use the tool if the
switch does not turn it on and off. Never attempt any repairsyourself.

WARNING: The use of any accessory or attachment or performance of any operation
with this tool other than those recommended in this instruction manual may present a
risk of personalinjury.
21 . Have your tool repaired by a qualifiedperson.
ʵ This electric tool complies with relevant safety rules. Repairs should only be carried out
by qualified persons using original spare parts; otherwise this may result in considerable
danger to theuser.
Additional Safety Rules For Thickness Planers
• Wear safety goggles, working gloves and ear protection whenoperating.
• Never operate the machine without all guards and anti-kickback device in place and in
perfect workingcondition.
• When planing, do not use the machine without the fence in position. Make sure that the lower
edge of the fence touches the upper tabletop.

WARNING: The infeed and outfeed table were accurately adjusted at the factory. Never
change the setting of the tablesyourself.
• Use only cutting blades designed for thismachine.
• Always use blades which are well sharpened andmaintained.
• Do not use the machine for working any material other than soft or hardwood.
• Never cut recesses, tenons or moulds. Rebating is notpermitted.
• Never carry out stopped work (i.e., cuts that do not involve working over the full length of
theworkpiece).
• Avoid working badly bowed wood providing inadequate contact with the infeedtable.
• Before use, check that the the kickback and feed spindles are functioningproperly.
• Remove all nails and metal objects from the workpiece before starting work. Do not use
splinterywood.
• In the planing mode, make sure the upper blade guard is adjusted to provide
optimumscreening.
• Ensure that the elevating handle is out of the feedarea.
• When working long pieces, use a suitable roller table on both sides of the machine adjusted to
the height of thetables.
• Keep your hands well clear of theblades.
• In the planing mode, use a push stick at alltimes.
• Keep the push stick in its place when not inuse.
• Refrain from removing any cut-offs or other parts of the workpiece from the cutting area
whilst the cutter block isrunning.
• Workpiece sizes:
ʵ Without additional support the machine is designed to accept the maximum workpiece
sizeof:
PLANER
• Height 140 mm by width 260 mm by length 500 mm
• Never cut workpiece shorter than 300 mm
THICKNESSER
• Height 160 mm by width 260 mm by length 600 mm
• Never cut workpiece shorter than 500 mm
ʵ Longer workpiece needs to be supported by suitable additional table, e.g., rollertable.
• In case of an accident or machine failure immediately switch the machine off and disconnect
fromsocket.
• Report the failure and mark the machine in suitable form to prevent other people from using
the defectivemachine.
• PLANER ONLY: When the cutter block is blocked caused by abnormal feed force during
cutting, switch the machine off and disconnect from power supply. Remove the workpiece
and ensure that the cutter block runs free. Switch the machine on and start new cutting
operation with reduced feedforce.
• Ensure that any portion of the cutterblock not being used for planing is safelyguarded.

WARNING: We recommend the use of a residual current device with a residual current
rating of 30mA orless.
Residual Risks
The following risks are inherent to the use of planers:
In spite of the application of the relevant safety regulations and the implementation of safety
devices, certain residual risks cannot beavoided.
These are:
• Risk of accidents caused by the uncovered parts of the rotatingblade.
• Risk of injury when changing theblade.
• Risk of squeezing fingers when opening theguards.
• Health hazards caused by breathing dust developed when planing wood, especially oak,
beech andMDF.
The following factors increase the risk of breathing problems:
• No dust extractor connected when sawingwood.
• Insufficient dust extraction caused by uncleaned exhaustfilters.
Electrical Safety
The electric motor has been designed for one voltage only (400 V – 3 Ph), and two voltages
only (230 – 1 Ph). Always check that the power supply corresponds to the voltage on the
ratingplate.
If the supply cord is damaged, it must be replaced by a specially prepared cord available
through the D
eWALT serviceorganization.
Mains Plug Replacement
(U.K. & Ireland only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
• Connect the yellow green lead to the peterminal.
Follow the fitting instructions supplied with good quality plugs. Recommended fuse: 13 A
(230Vonly).
Using an Extension Cable
If an extension cable is required, use an approved 3–core extension cable suitable for the
power input of this tool (seeTechnical data). The minimum conductor size is 1.5 mm
2
; the
maximum length is 20m.
When using a cable reel, always unwind the cablecompletely.
Package Contents
The package contains:
1 Partly assembled thickness planer
1 Guard
1 Guard/chip collector
1 Dust port adapter
1 Box containing:
1 Fence
1 Push stick
1 Bag containing:
1 Hex key 2.5 mm
1 Hex key 4 mm
1 Hex key 5 mm
1 Hex key 6 mm
1 Spanner 13/10 mm
1 Adjustment gauge
1 Elevating handle
2 Clamp handles
4 Rubber feet
1 M8 coach bolt
4 M8 nuts
4 D8 toothed washers
1 D8 flat washer
1 Box containing:
4 Legs
2 Wheels
2 Wheel brackets
1 Bag containing:
2 Wheel axles
4 M8 coach bolts
2 M8 hex head bolts
4 M8 nuts
4 Wing nuts
4 D8 flat washers
6 D8 Belleville washers
1 Instruction manual
• Check for damage to the tool, parts or accessories which may have occurred duringtransport.
• Take the time to thoroughly read and understand this manual prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
