NOTE: If using a dust extractor, lower the upper table all the way and attach the adapter to the
dust chute, then raise the upper table until is in contact with theadapter.
Adjustment

WARNING: Prior to adjustment always unplug thetool.
Adjusting the Fence (Fig. I1–I3)
Adjusting the Right Angle (Fig. I1)
The fence has an adjustable stop for easy right angleadjustment.
1. Loosen the angle clamp handle
40
.
2. Press the fence straight up to ensure it is fully vertical and tighten the angle clamphandle.
3. Place a set square
41
on the table and up against the fence
8
.
4. If adjustment is required, proceed as follows:
a. Loosen the nut
42
a few turns and turn the vertical position adjustment stop screw
43
in or out until the fence is at 90° to the table as measured with thesquare.
Adjusting the Chamfering Angle (Fig. I2)
1. Loosen the angle clamp handle
40
.
2. Move the fence
8
along its longitudinal axle to achieve the requiredangle.
3. Make sure that the lower edge of the fence touches the upper table top
9
.
4. Tighten the angle clamphandle.
Adjusting the Planing Width (Fig. I3)
1. Loosen the fence clamp handle
7
.
2. Move the fence
8
accross the upper table
9
to achieve the requiredwidth.
3. Tighten the fence clamphandle.
Adjusting the Guard (Fig. J)
The guard can be adjusted to any fixed position above the table to provide
optimumscreening.

WARNING: Always make sure to adjust the guard to the planing width and the height of
theworkpiece.
To Adjust the Width
1. Loosen the lock knob
44
.
2. Move the guard
13
to the requiredwidth.
3. Tighten the adjustmentknob.
To Adjust the Height
1. Loosen the clamp handle
12
.
2. Move the guard bracket
45
to the requiredheight.
3. Tighten the clamphandle.
Adjusting the Depth of Cut (Fig. K, L1–L3)
Planing Mode (Fig. K)
1. Loosen the locking ring
46
.
2. Take hold of the depth adjustment knob
10
and adjust the depth of cut using the
scale
47
.
- Turn clockwise to decrease the cuttingdepth.
- Turn counterclockwise to increase the cuttingdepth.
3. Tighten the lockingring.
Thicknessing Mode (Fig. L1–L3)
1. Place the elevating handle
2
on to the elevating shaft end
48
(Fig. L1).
2. Rotate the handle (clockwise) until it makes contact with the shaftnut.
3. Turn the elevating handle counterclockwise until it matches the hole and flat side of
theshaft.
4. Using a 2.5 mm hex key, tighten the dowel of the elevating handle (Fig. L2).
- Turn clockwise to decrease the cuttingdepth.
- Turn counterclockwise to increase the cuttingdepth.
5. Read the finished thickness of your workpiece on the depth adjustment scale
5
(Fig. L3).
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and applicableregulations.

WARNING: To reduce the risk of serious personal injury, turn tool off and
disconnect tool from power source before making any adjustments or removing/
installing attachments or accessories. Be sure the trigger switch is in the OFF position.
An accidental start-up can causeinjury.
Ensure the machine is placed to satisfy your ergonomic conditions in terms of table height
and stability. The machine site shall be chosen so that the operator has a good overview and
enough free surrounding space around the machine that allows handling of the workpiece
without anyrestrictions.
Prior to Operation
• Remove all foreign objects. Do not plane wood with loose knots. Do not plane wood that
is severely knotted orwarped.
Switching On and Off (Fig. M)
The on/off switch offers multiple advantages:
No-volt Release Function
Should the power be shut off for some reason, the switch has to be deliberatelyreactivated.
Motor Overload Protection Device
In case of motor overload, the power supply to the motor will be cut off. If this happens, let the
motor to cool for 2 minutes and then press the green startbutton.
1. To switch the machine on, press the green start button
53
.
2. To switch the machine off, press the red stop button
54
.

WARNING: Always switch off the machine when work is finished and beforeunplugging.
Planing (Fig. N1, N2)
1. Mount the guard/chip collector as describedabove.
2. Adjust the fence asrequired.
3. Adjust the guard to provide optimumscreening.
4. Set the depth ofcut.
5. Switch on themachine.
- Slowly feed the workpiece underneath the guard, keeping it firmly pressed against
thefence.
- Feed the workpiece in the direction of thegrain.
- Remember to use the push stick when close to thecutterhead.
Thicknessing (Fig. A2, O1, O2)
1. Mount the guard/chip collector as describedabove.
2. Lower the guard
13
.
3. Set the depth ofcut.
4. Switch on themachine.
- Best results are achieved when the workpiece has at least one flatsurface.
- For optimal results, plane both sides of the workpiece to reach the desiredthickness.
2.5
0.8
0
20 50 100 150 200
250
300
Follow the depth of cut and width guidelines shown in the table belo
w.
Width of stock (mm)
Softwood
Hardwood
Depth of cut (mm)
1.6
5. Slowly feed the workpiece into themachine.
6. Feed the workpiece in the direction of thegrain.
Snipe
Snipe is a depression made when the ends of the workpiece contact the cutters. To
avoidsnipe:
1. Keep the workpiece level throughout the planingoperation.
2. Feed the workpiece flat against thetable.
Warping (Fig. P1–P4)
If your workpiece is only slightly warped, plane both sides to produce the desiredthickness.
Bowed Workpieces (Fig. P1, P2)
The feed rollers and cutterhead will temporarily flatten the workpiece (Fig. P1). The bowed
shape, however, will return after planing (Fig.P2).
• To remove the bow, use ajointer.
Cupped Workpieces (Fig. P3, P4)
1. Rip the cupped workpiece in the middle (Fig. P3).
2. Plane the pieces separately to eliminatewaste.
3. Alternatively, plane the top flat
55
first, turn the workpiece over and plane the bottom
flat
56
(Fig. P4).
Dust Extraction (Fig. A1)
The machine is provided with a 100 mm dust extraction port on the guard/chip collector
4
.
Provided with a suitable dust extraction device, 90% of the produced shaving can be caught if
the air flow is at least 20 m/s.
Connect a suitable dust extraction device during alloperations.
Whenever possible, connect a dust extraction device designed in accordance with the relevant
regulations regarding dustemission.
Transporting (Fig. Q1, Q2)
The castor wheels
30
provide an easy transport of the machine. Securely holding the handle
with both hands, transport the machine as shown in FigureQ2.
