• Alwaysremovethebatteryfromthetoolandcovertheguidebar
(D) with the scabbard (J)  when transporting the saw.
• Engagechainbrakebypushingchain brake / front hand guard (C) forward.

WARNING: Read and understand all
 Failure to follow all instructions listed below may result
in electric shock, fire and/or serious personal injury.
• 
or death. See  “Guard Against
Kickback”, to avoid the risk of kickback.
•          
 Keep feet apart. Divide your weight
evenly on both feet.
• 
so that your body
is to the left of the guide bar.
•           
 Keep elbow of left arm locked so that left arm is straight to
withstand a kickback.
WARNING: (left
hand on the rear handle and right hand on the front handle).
WARNING:    
to be in line with the guide bar (D) when operating the chain saw.
• 


This chain saw is equipped with an auto oiling system that keeps the
saw chain and guide bar constantly lubricated. The oil level indicator
(I) shows the level of the oil in the chain saw. If the oil level is less than
a quarter full, remove the battery from the chain saw and refill with
the correct type of oil. Always empty oil tank when finished cutting.
NOTE: Use a high quality bar and chain oil for proper chain and
bar lubrication. As a temporary substitute, a non-detergent SAE30
weight motor oil can be used. The use of a vegetable based bar
and chain oil is recommended when pruning trees. Mineral oil is not
recommended because it may harm trees. Never use waste oil or
very
thick oil. These may damage your chain saw.

• Flip down locking lever and
unscrew counterclockwise a
quarter turn and then remove
the oil cap (P). Fill the reservoir
with the recommended bar and
chain oil until the oil level has
reached the top of the oil level
indicator (I).
• Refit the oil cap and tighten
clockwise a quarter turn. Flip
up locking lever to its locked
position.
• Periodically switch the chain saw off and check the oil level
indicator to ensure the bar and chain are being properly oiled.
FIG. 13
FIG. 12
I
P
