Variable Speed Trigger and Forward/
Reverse Control Button (Fig. A)
The tool is turned on and off by pulling and releasing the
variable speed trigger switch
3
. The farther the trigger
switch is depressed, the higher the speed of the tool. Your
tool is equipped with a brake. The chuck will stop as soon as
the trigger switch is fullyreleased.
A forward/reverse control button
4
determines the
rotational direction of the tool and also serves as a
lock-offbutton.
• To select forward rotation (clockwise), release the trigger
switch and depress the forward/reverse control button
on the right side of thetool.
• To select reverse (counterclockwise), depress the
forward/reverse control button on the left side of
thetool.
NOTE: The center position of the control button locks the
tool in the off position. When changing the position of the
control button, be sure the trigger isreleased.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
NOTE: The first time the tool is run after changing the
direction of rotation, you may hear a click on start-up. This is
normal and does not indicate aproblem.
Proper Hand Position (Fig. J)

WARNING: To reduce the risk of serious personal
injury, ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main
handle
15
, with the other hand on the side handle
14
to
control the twisting action of thedrill.
Installing and Removing the Battery Pack
(Fig. E)

WARNING: Ensure the tool/appliance is in the off
position before inserting the batterypack.
NOTE: For best results, make sure your battery pack is
fullycharged.
1. To install the battery pack
1
into the tool handle, align
the battery pack with the rails inside the tool’s handle
and slide it into the handle until the battery pack is firmly
seated in the tool and ensure that it does notdisengage.
2. To remove the battery pack from the tool, press the
battery pack release button
2
and firmly pull the battery
pack out of the tool handle. Insert it into the charger as
described in the charger section of thismanual.
OPERATION

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Speed Selection (Fig. A)
The tool features three speed settings for greaterversatility.
NOTE: Do not change speeds when the tool is running.
Always allow the tool to come to a complete stop before
changingspeed.
• To select speed 1(highest torque setting), turn the tool
off and permit it to stop. Slide the speed selector
8
all
the wayforward.
• Speed 2(middle torque and speed setting) is in the
middleposition.
• Speed 3(highest speed setting) is to therear.
If the tool does not change speeds, confirm that the
speed selector is completely engaged in the forward or
backposition.
If trouble shifting gears persists, depress and release the
trigger switch and tryagain.
Mode Selection (Fig. A)
The mode selection collar
5
can be used to select
the correct operating mode depending upon the
plannedapplication.
To select, rotate the collar until the desired symbol aligns
with thearrow.

WARNING: When the mode selection collar is in
the drill or hammerdrill positions, the drill will not
clutch. The drill may stall if overloaded, causing a
suddentwist.
Symbol Mode
Drilling
1-11 Screwdriving (higher number = greater torque)
Hammerdrilling

WARNING: The keyless chuck is unlocked after the first
click in the counterclockwise direction with the chuck
sleeve. Operation in the unlocked condition may cause
unintentional opening of the keylesschuck.
To insert a drill bit or other accessory, follow thesesteps.
1. Turn tool off and remove batterypack.
2. Grasp the black sleeve of the chuck with one hand
and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desiredaccessory.
3. Insert the accessory about 3/4" (19 mm) into the
chuck
6
and tighten securely by grasping and rotating
the chuck sleeve
7
clockwise with one hand while
holding the tool with the other. When the chuck is
nearly tightened you will hear a clicking sound. Continue
tightening as far as you can. Your tool is equipped with
an automatic spindle lock mechanism. This allows you to
open and close the chuck with onehand.
4. Be sure to tighten the chuck with one hand on the
chuck sleeve and one hand holding the tool for
maximum tightness. When tightening, do not turn in the
counterclockwisedirection.
5. To release the accessory, repeat steps 1and 2above.
