ENGLISH
DO NOT
use under wet conditions or in presence of flammable
liquids or gases.
These drills/drivers/hammerdrills are professional power tools.
DO NOT
let children come into contact with the tool.
Supervision is required when inexperienced operators use this tool.
• Young children and the infirm.
This appliance
is not intended for use by young children or infirm persons
without supervision.
•
This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills unless
they are supervised by a person responsible for their safety.
Children should never be left alone with this product.
Electrical Safety
The electric motor has been designed for one voltage only. Always
check that the battery pack voltage corresponds to the voltage on
the rating plate. Also make sure that the voltage of your charger
corresponds to that of your mains.
Your DeWALT charger is double insulated in
accordance with IEC60335; therefore no earth wire is
required.
If the supply cord is damaged, it must be replaced by a specially
prepared cord available through the DeWALT service organization.
Using an Extension Cable
An extension cord should not be used unless absolutely necessary.
Use an approved extension cable suitable for the power input of
your charger (see Technical Data). The minimum conductor
size is 1 mm
2
; the maximum length is 30 m.
When using a cable reel, always unwind the cable completely.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of
serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories. An accidental start-up
can cause injury.
WARNING: Use only DeWALT battery
packs and chargers.
Inserting and Removing the
Battery Pack from the Tool (Fig. 2)
NOTE: For best results, make sure your battery pack is fully
charged.
TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE
1. Align the battery pack (H) with the rails inside the tool’s
handle (Fig. 2).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that it does not disengage.
1 Kitbox
1
Charger
1 Side handle
1
Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included with
N-models. Battery packs and chargers are not included with NT
models. Bmodels include Bluetooth
®
battery packs.
NOTE: The Bluetooth
®
word mark and logos are registered
trademarks owned by the Bluetooth
®
, SIG, Inc. and any use of such
marks by DeWALT is under license. Other trademarks and trade
names are those of their respective owners.
• Check for damage to the tool, parts or
accessories which may have occurred during
transport.
• Take the time to thoroughly read and
understand this manual prior to operation.
Description (Fig. 1)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury could result.
A. Trigger switch
B. Forward/reverse control button
C. Worklight
D. Chuck
E. Torque adjustment collar
F. Gear shifter
G. Side handle
H. Battery pack
I. Battery release button
J. Belt hook
K. Mounting screw
L. Magnetic bit holder
M. Worklight switch
N. Low worklight mode
O. Medium worklight mode
P. Spotlight mode
Q. Fuel gauge
R. Main handle
INTENDED USE
These drills drivers/hammerdrills are designed for professional
drilling, percussion drilling and screwdriving applications. This tool
is compatible with Bluetooth
®
Battery Technology and with the
DeWALT Tool Connect
TM
App. Please see your Tool Connect
TM
App
instruction manual for more information.
