4
ENGLISH
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
English (original instructions)
HEAVY-DUTY CORDLESS ROTARY HAMMERDRILL
DCH243, DCH253, DCH254, DCH273, DCH274, DCH283
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
DCH243 DCH253 DCH254 DCH273 DCH274 DCH283
Voltage V
DC
18 18 18 18 18 18
Type 1/2 1/2 1 1/2 1 1
No-load speed min
-1
0–1150 0–1200 0–1200 0–1100 0–1100 0–980
No-load Impact rate bpm 0–4400 0–4500 0–4500 0–4600 0–4600 0–4480
Single impact energy (EPTA 05/2009) J 2.1 2.1 2.1 2.1 2.1 2.8
Maximum drilling range in steel/wood/concrete mm 13/26/20 13/26/24 13/26/24 13/26/24 13/26/24 13/30/26
Chuck SDS Plus SDS Plus SDS Plus SDS Plus SDS Plus SDS Plus
Collar diameter mm 54 54 54 54 54 54
Battery Type Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion
Weight (without battery pack) kg 2.4 2.5 2.7 2.5 2.7 3.6
Noise values and/or vibration values (triax vector sum) according to EN60745-2-6:
L
PA
(emission sound pressure level) dB(A) 86 86 86 86 86 94
L
WA
(sound power level) dB(A) 97 97 97 97 97 105
K
(uncertainty for the given sound level) dB(A) 3 3 3 3 3 3
Drilling into concrete
Vibration emission value a
h, HD
= m/s² 7.4 6.6 6.6 6.6 6.6 8.5
Uncertainty K = m/s² 1.5 1.5 1.5 1.5 1.5 1.5
Chiselling
Vibration emission value a
h
, Cheq
= m/s² 6.0 5.4 5.4 5.4 5.4 8.5
Uncertainty K = m/s² 1.5 1.5 1.5 1.5 1.5 1.5
Drilling into metal
Vibration emission value a
h
,
D
= m/s² ≤ 2.5 ≤ 2.5 ≤ 2.5 ≤ 2.5 ≤ 2.5 ≤ 2.5
Uncertainty K = m/s² 1.5 1.5 1.5 1.5 1.5 1.5
Screwdriving
Vibration emission value a
h
= m/s² ≤ 2.5 ≤ 2.5 ≤ 2.5 ≤ 2.5 ≤ 2.5 ≤ 2.5
Uncertainty K = m/s² 1.5 1.5 1.5 1.5 1.5 1.5
