DeWalt DCH733 Service Training

H
H
Assembling Lubrication
DCH733 D25733 D25872 D25773 D25892
Gear
Case/Clutch
Crank Shaft Cylinder Piston
Ram
Bevel Gear
Front Housing Damper Bush
Washer
20g Paragon 40g GLK 15Paragon 12g GLK 12g GLK
6g Paragon
( O-Ring Groove)
10g GLK
20g Paragon 40g GLK 15Paragon 12g GLK 12g GLK
6g Paragon
( O-Ring Groove)
10g GLK
30g Paragon 40g GLK 15Paragon 12g GLK 12g GLK
6g Paragon
( O-Ring Groove)
10g GLK
20g Paragon 40g GLK 30Paragon 12g GLK 12g GLK
6g Paragon
( O-Ring Groove)
10g GLK
30g Paragon 40g GLK 30Paragon 12g GLK 12g GLK
6g Paragon
( O-Ring Groove)
10g GLK
DCH733
D25733
D25872
D25773
D25892
The surface of internal components like gears, crankshaft, cylinder and front housing have to be coated by grease
Note: The inner sure face of the spindle, as well the beat piece have to be lubricated by a coating of Paragon
