DeWalt DCM5713 User Manual

12
ENGLISH

WARNING: To reduce the risk of serious
personal injury, turn tool off and disconnect battery
pack before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Proper Hand Position (Fig. A, E)

WARNING: To reduce the risk of serious
personal injury, ALWAYS use proper hand position
asshown.

WARNING: To reduce the risk of serious
personal injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the handle
3
, with
the other hand on the auxiliary handle
5
.
Switching On (Fig. A)
To turn the appliance on, push the lock off tab
32
forward,
squeeze the lock-off lever
2
, and then squeeze the variable
speed trigger
1
.
To turn the appliance off, release the variable speed trigger, the
lock-off lever, andtab.
Speed Control Switch (Fig. A)
This Grass Trimmer gives you the choice to operate at a
more efficient speed to extend the runtime for larger jobs, or
accelerate the trimmer speed for high-performance cutting.
To extend runtime, push the speed control switch
4
forward
toward the auxiliary handle
5
into the "LO" position. This mode
is best for larger projects that require more time tocomplete.
To accelerate the trimmer, pull the speed control switch back
toward the battery housing
12
into the "HI" position. This mode
is best to cut through heavier growth and for applications that
need higherRPM.
NOTE: When in "HI" mode, runtime will be decreased as
compared to when trimmer is in "LO"mode.
Trimming (Fig. A, E, F)
With the trimmer on, angle it and swing side to side as shown
in FigureE.
Maintain a minimum distance of 610 mm between the guard
and your feet as shown in FigureF.

WARNING: Keep the rotating string roughly
parallel with the ground (tilted no more than 30 degrees).
This trimmer is not an edger. DO NOT TILT the trimmer so
that the string is spinning near a right angle to the ground.
Flying debris can cause seriousinjury.
Bump Feed Trimmer Line Feed
Your trimmer uses 2.032 mm diameter nylon line. Cutting line
will wear faster and require more feeding if the cutting is done
along sidewalks or other abrasive surfaces or heavier weeds are
beingcut.
As you use the trimmer, the string will get shorter due to wear.
Gently bump the trimmer on the ground while running at
normal speed and the line willfeed.
NOTE: Extending nylon line beyond the 330mm swath will
negatively affect performance, runtime, and the life of the
trimmer due to potential of damaging motor. Doing so may
void thewarranty.
Helpful Cutting Tips
• Use the tip of the string to do the cutting; do not force string
head into uncutgrass.
• Wire and picket fences cause extra string wear, even
breakage. Stone and brick walls, curbs, and wood may wear
stringrapidly.
• Do not allow spool cap to drag on ground or othersurfaces.
• In long growth, cut from the top down and do not exceed
304.8 mmhigh.
• Keep trimmer tilted toward the area being cut; this is the
best cuttingarea.
• The trimmer cuts when passing the unit from the left to
right. This will avoid throwing debris at the operator.
• Avoid trees and shrubs. Tree bark, wood moldings, siding, and
fence posts can easily be damaged by thestring.
Replacement Accessories

WARNING: To reduce the risk of serious
personal injury, turn tool off and disconnect battery
pack before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.

WARNING: The use of any accessory not
recommended by D
e
WALT for use with this appliance
could behazardous.

WARNING: Do not use any blades, or any
accessory or attachment other than those recommended
by D
e
WALT on this trimmer. Serious injury or product
damage mayresult.
Use D
e
WALT replacement line Model No. DT20650 (2mm),
DT20651 (2mm), DT20652 (2.5mm).
• For optimal performance, use Dewalt DT20650/51.
DeWALT
DT20652 can also be use but may degrade runtime of the
trimmer. Using any other line with the trimmer can degrade
performance and/or cause damage to thetrimmer.

DeWalt DCM5713 Specifications

General

Brand	DeWalt
Model	DCM5713
Category	Trimmer
Language	English
