ENGLISH
38
18V XR LI-ION CORDLESS FRAMING NAILER
DCN690
Congratulations!
You have chosen a DEWALT tool. Years of
experience, thorough product development and
innovation make DEWALT one of the most reliable
partners for professional power tool users.
Technical Data
DCN690
Voltage V
DC
18
Type 1
Actuating mode Sequential/Bump
Magazine angle 33°
Fasteners
length mm 50–90
shank diameter mm 2.8–3.3
angle 30–34°
head geometry clipped or offset round
collation type paper
Weight (without battery pack)
kg 3.53
Drive energy J 105
L
PA
(sound pressure) dB(A)
84
K
PA
(sound pressure
uncertainty) dB(A)
3
L
WA
(sound power) dB(A)
95
K
WA
(sound power
uncertainty) dB(A)
3
Vibration total values (triax vector sum) determined according to
EN 60745:
Vibration emission value a
h
a
h
=
m/s²
3.8
Uncertainty K = m/s²
1.5
The vibration emission level given in this information
sheet has been measured in accordance with a
standardised test given in EN 60745 and may be
used to compare one tool with another. It may be
used for a preliminary assessment of exposure.
WARNING: The declared vibration
emission level represents the main
applications of the tool. However if the
tool is used for different applications, with
different accessories or poorly maintained,
the vibration emission may differ. This
may significantly increase the exposure
level over the total working period.
An estimation of the level of exposure to
vibration should also take into account
the times when the tool is switched off
or when it is running but not actually
doing the job. This may significantly
reduce the exposure level over the total
working period.
Identify additional safety measures to
protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,
organisation of work patterns.
Battery pack DCB180 DCB181 DCB182
Battery type Li-Ion Li-Ion Li-Ion
Voltage V
DC
18 18 18
Capacity Ah 3.0 1.5 4.0
Weight kg 0.64 0.35 0.61
Charger DCB105
Mains voltage V
AC
230
Battery type Li-Ion
Approx. charging min 30 55 70
time (1.5 Ah (3.0 Ah (4.0 Ah
packs) packs) packs)
Weight kg 0.49
Fuses
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
Defi nitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
