DeWalt DCN701 - Cold Weather Operation; Hot Weather Operation; Maintenance

39
ENGLISH

WARNING: Always remove battery pack before loading or
unloadingstaples.

CAUTION: Keep fingers clear of pusher latch track to
preventinjury.

WARNING: This stapler requires the use of
D
e
WALTstaples.
1. Depress magazine release button
7
and slide the magazine
core and pusher
8
out until it reaches the end of itstravel.
2. Drop staple strips into the loading slot of the magazine
6
,
making sure the staple heads align correctly with the
slot opening. (Refer to Technical Data to determine
compatiblesize.)
3. Keeping fingers clear of the track, close the magazine by
releasing the pusher latch. Carefully allow the latch to slide
forward and engage the staplestrip.
NOTE: Do not slam magazine core assembly into magazine
or you could damagestaples.
Unloading the Tool

WARNING: Always remove battery pack before loading or
unloadingstaples.
1. Depress magazine release button
7
and slide the magazine
core and pusher
8
out until it reaches the end of itstravel.
2. Tip the tool right side up until the staple strips fall freely out
of themagazine.
3. Close the magazine by sliding the magazine core back into
the magazine fully until it latches. Do not slam magazine
core into themagazine.
Headlight/LED Worklight (Fig. F)
There is a headlight/LED worklight
5
located at the front of the
unit. The headlight turns on upon battery insertion, activation
of the trigger, or depressing the contact trip. The light will
automatically shut off after 20 seconds unless tool remains
inuse.
NOTE: The headlight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
LOW BATTERY INDICATOR: The headlight will flash four
consecutive times and then shut down to indicate lowbattery.
Actuating the Tool (Fig. G)

WARNING: Always turn off power to circuit before
attempting to staple wires. Do not staple “live”wires.

WARNING: Always assume that the tool contains staples.
Careless handling of the stapler can result in unexpected
firing of staples and personal injury. Do not point the tool
towards yourself or anyone nearby. Unexpected triggering
could discharge a staple causing an injury. No horseplay!
Work Safe! Respect the tool as a workingimplement.

WARNING: Do not actuate the tool unless the tool is
placed firmly against the workpiece. If the tool is not in
contact with the workpiece, the staple may be deflected
away from yourtarget.
There is no need for depthadjustment.
1. Load unit withstaples.
2. Place battery intotool.
3. Locate cable alignment guide
3
directly over the cable or
wire you wish to staple so that the wire is centered as much
as possible between the 2 prongs of the cableguide.

WARNING: Staples must be driven straight into the
material. Do not tilt stapler while driving staples. Refer to
Figure G. Staple retention values improve when tool is fired
perpendicular to thematerial.
4. Push tool against cable firmly to depress cable alignment
guide
3
all the way as well as wire indicator
4
, pull
trigger
1
and a staple will befired.
5. Check wire for damage after eachshot.
NOTE: When fastening into certain wood materials, additional
force applied towards the wood may be needed to properly
seat thestaple.

WARNING: Use caution in locating stapler over cable or
wire to prevent the staple from piercing the cable jacket or
insulation. After firing each staple, visually inspect driven
staple to make sure wire insulation was not damaged. If
damaged replacewire.
Clearing a Jammed Staple (Fig. A, H)

WARNING: To reduce the risk of serious personal injury,
disconnect battery pack from tool before making any
adjustments, changing accessories, servicing, or moving
the tool. Such preventative safety measures reduce the risk
of firing the tool accidentally.
1. Remove battery pack
10
fromtool.
2. Depress magazine latch
7
and slide the magazine core and
pusher
8
out until it reaches the end of itstravel.
3. Tip the tool right side up until any loose staple strips fall
freely out of the magazine. Any jammed staples can then
beremoved.
4. Refill magazine with newstaples.
Cold Weather Operation
When operating tools at temperatures below freezing:
1. Keep tool as warm as possible prior touse.
2. Actuate the tool a few times into scrap lumber over a piece
of scrap cable beforeusing.
Hot Weather Operation
Tool should operate normally. However, keep tool out of direct
sunlight as excessive heat can deteriorate bumpers and other
rubber parts resulting in increasedmaintenance.
MAINTENANCE
Your
DeWALT
power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before loading staples, making any adjustments or
removing/installing attachments or accessories. An
accidental actuation can causeinjury.
The charger and battery pack are notserviceable.
