43
ENGLISH
and is flush with the shaft. Ensure the accessory
is oriented as shown in figure 4.
4. Release the accessory clamp lever.
NOTE: Some accessories, such as scrapers and
blades can be mounted at an angle if required as
shown in figure 5.
INSTALLING/REMOVING SANDING SHEETS (FIG. 6)
A diamond shaped platen uses a hook and loop
adhesion system to attach the sanding sheets. The
platen allows you to use it on large flat surfaces and
tight spots or corners.
1. Attach the sanding platen (w) as described
under Installing/Removing Accessories.
2. Align the edges on the sanding sheet, with
the edge of the sanding platen and press the
sanding sheet (x) onto the platen.
3. Firmly press the base with the sanding sheet
attached against a flat surface and briefly switch
the tool on. This provides for good adhesion
between the platen and the sanding sheet and
also helps to prevent premature wear.
4. When the tip of the sanding sheet becomes
worn, detach the sheet from the platen, rotate
and reapply.
ATTACHING ACCESSORIES USING THE UNIVERSAL
ADAPTER (FIG. 7)
CAUTION: To avoid injury, do not
use any accessory for an application
where the adaptor may fail to hold the
accessory.
CAUTION: Read and follow all
manufacturers' safety warnings for any
accessories used with this tool.
CAUTION: To avoid injury, ensure
adaptor and accessory are securely
tightened.
Non-DEWALT accessories can be attached using
the universal adaptor.
1. Place the washer (k) on the tool.
2. Place accessory (l) on to washer.
3. Tighten and secure adaptor nut (p) using hex
wrench (r).
Attaching the Cut Guide (fi g. 8–13)
The depth/cut guide allows you to precisely cut
material at a specified depth and more accurately
track a marked cut line.
WARNING: Use only DEWALT battery
packs and chargers.
Inserting and Removing the
Battery Pack from the Tool (fi g. 2)
NOTE: For best results, make sure your battery
pack is fully charged.
TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE
1. Align the battery pack (h) with the rails inside the
tool’s handle (fig. 2).
2. Slide it into the handle until the battery pack is
firmly seated in the tool and ensure that it does
not disengage.
TO REMOVE THE BATTERY PACK FROM THE TOOL
1. Press the battery release button (i) and firmly
pull the battery pack out of the tool handle.
2. Insert battery pack into the charger as
described in the charger section of this manual.
FUEL GAUGE BATTERY PACKS (FIG. 2)
Some D
EWALT battery packs include a fuel gauge
which consists of three green LED lights that
indicate the level of charge remaining in the battery
pack.
To actuate the fuel gauge, press and hold the fuel
gauge button (j). A combination of the three green
LED lights will illuminate designating the level of
charge left. When the level of charge in the battery
is below the usable limit, the fuel gauge will not
illuminate and the battery will need to be recharged.
NOTE: The fuel gauge is only an indication of the
charge left on the battery pack. It does not indicate
tool functionality and is subject to variation based
on product components, temperature and end-user
application.
Installing/Removing Accessories
(fi g.3–7)
TOOL-FREE ACCESSORY CLAMP (FIG. 3–5)
The DCS355 features a quick change accessory
system. This allows for faster accessory changes
without the need for wrenches or hex keys like other
oscillating tool systems.
1. Grasp the tool and squeeze the accessory
clamping lever (c) as shown in figure 3.
2. Clean any residual debris from the tool shaft
and the accessory holder.
3. Slide the accessory between the shaft (v)
and the accessory holder making sure the
accessory engages all eight pins on the holder
To Next Page
