DeWalt DCS577 Original Instructions

13
ENGLISH
Inserting and Removing the Battery Pack
from the Tool (Fig.B)
NOTE: Make sure your battery pack
15
is fullycharged.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.

WARNING: Use only
DeWALT
battery packs andchargers.
Description (Fig.A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Trigger switch lock off
button
2
Trigger switch
3
Depth adjustment locking
lever
4
Lower blade guard
retracting lever
5
Foot plate
6
Lower blade guard
7
0˚ Kerf indicator
8
45˚ Kerf indicator
9
Bevel adjustment lever
10
Angle quadrant
11
Spindle lock button
12
Main handle
13
Auxiliary handle
14
Battery release button
15
Battery
16
Coarse adjustment
17
Fine adjustment
18
Kerf indicators
19
Blade clamping screw
20
Dust extraction port
21
Wrench
22
Date code
Intended Use
These heavy‑duty circular saws are designed for professional
wood cutting applications. DO NOT use water feed attachments
with this saw. DO NOT use abrasive wheels orblades.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
These heavy‑duty saws are professional powertools.
Do not let children come into contact with the tool. Supervision
is required when inexperienced operators use thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Date Code Position (Fig.A)
The date code
22
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Package Contents
The package contains:
1 Hi‑torque circular saw
1 Circular saw blade
1 Blade wrench
1 Dust extraction port
2 Dust port screws
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by
DeWALT
is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Battery Type
The following SKU(s) operate on a 54 volt battery pack: DCS577
These battery packs may be used: DCB546, DCB547, DCB548.
Refer to Technical Data for moreinformation.
Only for indooruse.
Discard the battery pack with due care for
theenvironment.
Charge
DeWALT
battery packs only with designated
DeWALT
chargers. Charging battery packs other
than the designated
DeWALT
batteries with a
DeWALT
charger may make them burst or lead to
other dangeroussituations.
Do not incinerate the batterypack.
USE (without transport cap). Example: Wh rating
indicates 108Wh (1 battery with 108Wh).
TRANSPORT (with built‑in transport cap). Example:
Wh rating indicates 3x 36Wh (3batteries of 36Wh).

DeWalt DCS577 Specifications

General

Quantity per pack	1 pc(s)
