DeWalt DCS577 Original Instructions

16
ENGLISH
Blades

WARNING: To minimise the risk of eye injury, always
use eye protection. Carbide is a hard but brittle material.
Foreign objects in the workpiece such as wire or nails
can cause tips to crack or break. Only operate saw when
proper saw blade guard is in place. Mount blade securely
in proper rotation before using, and always use a clean,
sharpblade.
Do not use abrasive wheels or blades. A dull blade will cause
slow, inefficient cutting resulting in overload to the saw motor,
excessive splintering and could increase the possibility of
kickback. Please refer to the following table to determine the
correct size replacement blade for your modelsaw.
DCS577
Blade Diameter Teeth Application
DT40270 190 mm 24 General purpose wood cutting
DT40271 190 mm 36 Plywood cutting
Kickback
Kickback is a sudden reaction to a pinched, bound or misaligned
saw blade, causing an uncontrolled saw to lift up and out of the
workpiece toward the operator. When the blade is pinched or
bound tightly by the kerf closing down, the blade stalls and the
motor reaction drives the unit rapidly back toward the operator.
If the blade becomes twisted or misaligned in the cut, the teeth
at the back edge of the blade can dig into the top surface of the
wood causing the blade to climb out of the kerf and jump back
toward theoperator.
Kickback is more likely to occur when any of the following
conditionsexist.
1. IMPROPER WORKPIECE SUPPORT
a. Sagging or improper lifting of the cut off piece can cause
pinching of the blade and lead to kickback(Fig.Q).
b. Cutting through material supported at the outer ends
only can cause kickback. As the material weakens it sags,
closing down the kerf and pinching theblade.
c. Cutting off a cantilevered or overhanging piece of
material from the bottom up in a vertical direction
can cause kickback. The falling cut off piece can pinch
theblade.
d. Cutting off long narrow strips(as in ripping) can cause
kickback. The cut off strip can sag or twist closing the kerf
and pinching theblade.
e. Snagging the lower guard on a surface below the
material being cut momentarily reduces operator control.
The saw can lift partially out of the cut increasing the
chance of bladetwist.
2. IMPROPER DEPTH OF CUT SETTING ON SAW
a. To make the most efficient cut, the blade should protrude
only far enough to expose half of a tooth as shown in
FigureE. This allows the foot plate to support the blade
and minimises twisting and pinching in the material. See
the section titled Cutting DepthAdjustment.
5. Place outer clamp washer
27
on saw spindle
29
with the
large flat surface against the blade and the wording on the
outer clamp washer facing you as shown in FigureN.
6. Thread the blade clamping screw
19
into saw spindle by
hand(screw has left‑hand threads and must be turned
counterclockwise totighten).
7. Slowly release the lower blade guard retracting lever
4
.
8. Depress the spindle lock button
11
while turning the saw
spindle with the blade wrench provided until the blade
lock engages and the blade stops rotating. Using the blade
wrench, firmly tighten blade clampingscrew.
NOTICE: Never engage the blade lock while saw is
running, or engage in an effort to stop the tool. Never
turn the saw on while the blade lock is engaged. Serious
damage to your saw willresult.
To Replace the Blade(Fig.A, N)
1. Depress the spindle lock button
11
while turning the saw
spindle with the blade wrench provided until the blade lock
engages and the blade stopsrotating.
2. With the blade wrench provided
21
, loosen the blade
clamping screw
19
by turning it clockwise as indicated by
the arrow on the outer clamp washer
27
.
3. Remove the outer clamp washer
27
.
4. Using the lower blade guard retracting lever
4
, retract the
lower blade guard. Remove used blade and properlydiscard.
5. Install new blade as previouslydescribed.
6. Clean any sawdust that may have accumulated in the guard
or clamp washer area. Check the condition and operation
of the lower blade guard as previously outlined. Do not
lubricate thisarea.
7. Select the proper blade for the application(refer to Blades).
Always use blades that are the correct size(190mm
diameter) with the proper size and shape centre hole
for mounting on the saw spindle. Always assure that the
maximum recommended speed(rpm) on the saw blade
meets or exceeds the speed(rpm) of thesaw.
Lower Blade Guard

WARNING: The lower blade guard is a safety feature
which reduces the risk of serious personal injury.
Never use the saw if the lower guard is missing,
damaged, misassembled or not working properly.
Do not rely on the lower blade guard to protect you
under all circumstances. Your safety depends on
following all warnings and precautions as well as
proper operation of the saw. Check lower guard for
proper closing before each use as outlined in Safety
Instructions for All Saws. If the lower blade guard
is missing or not working properly, have the saw
serviced before using. To assure product safety and
reliability, repair, maintenance and adjustment
should be performed by an authorised service centre
or other qualified service organisation, always using
identical replacementparts.
