30
ENGLISH
MITRE SAW DW017
Congratulations!
You have chosen a DEWALT tool. Years of experience, thorough product
development and innovation make DEWALT one of the most reliable
partners for professional power tool users.
Technical data
DW017
Sound pressure (L
pA
) dB(A) 88
Acoustic power (L
WA
) dB(A) 101
Hand/arm weighted vibration m/s
2
< 2.5
Voltage V 24
Power output W 630
Blade diameter mm 216
Blade bore mm 30
Max. blade thickness mm 1.6
Max. blade speed min
-1
4,000
Max. crosscut capacity at 90° mm 300
Max. mitre cut capacity at 45° mm 212
Max. depth of cut 90° mm 70
Max. depth of bevel cross-cut 45° mm 50
Mitre (max. positions)
left 50°
right 60°
Bevel (max. positions)
left 48°
right 2°
0° mitre
Resulting width at max. height 70 mm mm 300
Resulting height at max. width 300 mm mm 70
45° mitre left
Resulting width at max. height 70 mm mm 212
Resulting height at max. width 212 mm mm 70
45° mitre right
Resulting width at max. height 70 mm mm 212
Resulting height at max. width 212 mm mm 70
45° bevel left
Resulting width at max. height 50 mm mm 300
Resulting height at max. width 300 mm mm 50
31.62° mitre, 33.85° bevel
Resulting height at max. width 254 mm mm 65
Automatic blade brake time s < 5.0
Dust collection efficiency mg/m
3
< 2.0
Weight kg 20.5
Battery pack DE0242 DE0241
Battery type NiCd NiMH
Voltage V 24 24
Weight kg 1.4 1.4
Charger DE0246
Mains voltage V
AC
230
Approx. charging time min 60/70
Weight kg 0.6
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or damage to the
tool in case of non-observance of the instructions in this
manual.
Denotes risk of electric shock.
EC-Declaration of conformity
DW017
DEWALT declares that these power tools have been designed in
compliance with: 98/37/EEC, 89/336/EEC, EN 55014-2, EN 55014-1,
EN 60335, EN 61000-3-2, EN 61000-3-3, EN 50260-1 & EN 61029.
For more information, please contact DEWALT at the address below or
refer to the back of the manual.
Director Engineering and Product Development
Horst Großmann
DEWALT, Richard-Klinger-Straße 40,
D-65510, Idstein, Germany
