en - 1 16
ENGLISH
JIGSAW DW322/DW321/DW323/DW324
Congratulations!
You have chosen a DEWALT Power Tool. Years of
experience, thorough product development and
innovation make DEWALT one of the most reliable
partners for professional Power Tool users.
Table of contents
Technical data en - 1
EC-Declaration of conformity en - 2
Safety instructions en - 2
Package contents en - 3
Description en - 3
Electrical safety en - 4
Mains plug replacement (U.K. & Ireland only) en - 4
Using an extension cable en - 4
Assembly and adjustment en - 4
Instructions for use en - 6
Maintenance en - 7
Guarantee en - 7
Technical data
DW322 DW321 DW323 DW324
Voltage V 230 230 230 230
(U.K. & Ireland only) V 230/115 230/115 230/115 230/115
Power input W 650 701 701 650
Power output W 410 445 425 410
No load speed min
-1
3,100 500-3,100 500-3,100 3,100
Stroke length mm 26 26 26 26
Cutting depth in:
- wood mm depending depending depending depending
on blade on blade on blade on blade
- aluminium mm 20 20 20 20
- steel mm 10 10 10 10
- in stainless steel alloy mm - 3 3 -
Mitre angle range (left and right) 0 - 45° 0 - 45° 0 - 45° 0 - 45°
Weight kg 2.4 2.4 2.4 2.4
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
The following symbols are used throughout this
manual:
Denotes risk of personal injury, loss of life
or damage to the tool in case of non-
observance of the instructions in this
manual.
Denotes risk of electric shock.
