ENGLISH
4
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
COMPONENTS (FIG. A)

WARNING: Never modify the pneumatic tool or any
part of it. Damage or personal injury couldresult.
Refer to Figure A at the beginning of this manual for a
complete list ofcomponents.
Intended Use
Your lathing stapler is designed for professional
fasteningapplications.
DO NOT use under wet conditions or in presence of
flammable liquids orgases.
This lathing stapler is a professional pneumatictool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
TOOL SPECIFICATIONS
DW451S2
Description 1" Crown stapler
Operation pressure range 70–120 p.s.i.g. (4.9–8.5 kg/cm
2
)
Fastener type D
e
WALT and BOSTITCH 16S2 Series staples
Fastener gauge 16
Fastener range 1"–2"
Magazine capacity 140 staples
Length 14 1/2" (368 mm)
Width 3 1/8" (79 mm)
Height 10 3/4" (273 mm)
Weight 5.3 lbs (2.4 kg)
Tool Air Fitting
This tool uses a free-flow connector plug, 1/4" N.P.T. The
minimum inside diameter should be .200" (5 mm). The
fitting must be capable of discharging tool air pressure
when disconnected from the airsupply.
Operating Pressure
70–120 p.s.i.g. (4.9–8.5 kg/cm
2
). Select the operating
pressure within this range for best fastener performance. DO
NOT EXCEED THIS RECOMMENDED OPERATINGPRESSURE.
Air Consumption
The DW451S2 requires 5.3 cubic feet per minute or C.F.M.
(150 liters per minute or LT/MIN) of free air at 80 p.s.i.g.
(5.6kg/cm
2
) to operate at a rate of 100 fasteners per minute.
To determine the appropriately sized air compressor, take
the actual rate at which the tool will be run and compare
the required C.F.M. (LT/MIN) to the compressors free air
delivery (C.F.M./ LT/MIN) at 80 p.s.i.g. (5.6 kg/cm
2
).
For example, if your fastener usage averages 50 fasteners
per minute, you need 50% of the tools C.F.M. required to
operate the tool at the rate of 100 fasteners per minute.
In this case, be sure that your air compressor can deliver a
minimum of 2.7 C.F.M. (75 LT/MIN) at 80 p.s.i.g. (5.6 kg/cm
2
)
for optimumperformance.
FASTENER SPECIFICATIONS
DW451S2
Fastener Gauge Crown width Length
D
e
WALT DW16S2-25GAL 16 1" 1"
D
e
WALT DW16S2-38GAL 16 1" 1 1/2"
BOSTITCH 16S2-25FG 10M 16 1" 1"
BOSTITCH 16S2-25SG 10M 16 1" 1"
BOSTITCH 16S2-31FG 10M 16 1" 1 1/4"
BOSTITCH 16S2-31SG 10M 16 1" 1 1/4"
BOSTITCH 16S2-38FG 10M 16 1" 1 1/2"
BOSTITCH 16S2-38SG 10M 16 1" 1 1/2"
BOSTITCH 16S2-44FG 10M 16 1" 1 3/4"
BOSTITCH 16S2-44SG 10M 16 1" 1 3/4"
BOSTITCH 16S2-50FG 10M 16 1" 2"
BOSTITCH 16S2-50SG 10M 16 1" 2"
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove air supply before
making any adjustments or removing/installing
attachments or accessories. An accidental
actuation can causeinjury.
Adjustments and Usage Prep
Air Supply and Connections

WARNING: Do not use oxygen, combustible
gases, or bottled gases as a power source for this
tool as tool may explode, possibly causinginjury.
Fittings
Install a male fitting on the tool which is free flowing
and which will release air pressure from the tool when
disconnected from the supplysource.
Hoses
Air hoses should have a minimum of 150 p.s.i.g.
(10.6kg/cm²) working pressure rating or 150 percent of
the maximum pressure that could be produced in the air

WARNING: Use of this tool can generate and/
or disperse dust, which may cause serious and
permanent respiratory or other injury. Always use
NIOSH/OSHA approved respiratory protection
appropriate for the dust exposure. Direct particles
away from face andbody.

WARNING: Always wear proper personal hearing
protection that conforms to ANSI S12.6 (S3.19)
during use. Under some conditions and duration
of use, noise from this product may contribute to
hearingloss.

CAUTION: When not in use, place tool on its
side on a stable surface where it will not cause
a tripping or falling hazard. Some tools will stand
upright but may be easily knockedover.
