DeWalt DWMT70776 - DEWALT Air Ratchet Overview; Key Component Identification; Product Specifications

2
English
A. 3/8" Square Drive
B. Exhaust
C. Aluminum Body
D. Tr igger
E. 1/4"Air Inlet
SPECIFICATIONS
MODEL
DWMT70776L
SQUARE DRIVE
3/8"
MAXIMUM TORQUE (REVERSE)
75 Ft.Lbs (100 Nm)
FREE SPEED (@90PSI)
180 RPM
NET WEIGHT
2.6 LBS (1.2Kg.)
EXHAUST TYPE
Front
AVERAGE AIR CONSUMPTION FREE
SPEED
25 SCFM (12 L/s)
3.6 CFM (1.7L/s)
AVERAGE AIR CONSUMPTION AT LOAD
15.0 SCFM (7.1 L/s)
2.1 CFM (1.0 L/s)
AIR INTLET SIZE
1/4" NPT(F)
RECOMMENDED HOSE SIZE
3/8" (10MM)
MAX. AIR PRESSURE
90 PSI
DWMT70776L
3/8" AIR RATCHET
F. Ergonomic Handle
G. Forward/Reverse Switch
H. Closed Head
FIG.1
A
B
C
D
E
F
G
H
