DeWalt DWS520 Original Instructions

ENGLISH
5
EC-Declaration of Conformity
Machinery Directive
Plunge Saw
DWS520
DeWALT
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841-1:2015; EN62841-2-5:2014.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Director Engineering
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
10.08.2016
WARNING: To reduce the risk of injury, read the
instruction manual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.

WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.

CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
DWS520
GB/XE
DWS520
LX
Voltage V
AC
230 115
Type 3 3
Power output W 1300 1300
No-load speed min
-1
1750-4200 1750-4200
Blade diameter mm 165 165
Maximum depth of cut
90˚ (without guide rail) mm 59 59
90˚ (with guide rail) mm 55 55
Blade bore mm 20 20
Bevel angle adjustment 47˚ 47˚
Weight kg 5 5
Noise values and vibration values (triax vector sum) according to EN62841-2-5:
L
PA
(emission sound pressure level) dB(A) 91 91
L
WA
(sound power level) dB(A) 102 102
K (uncertainty for the given sound level) dB(A) 3 3
Vibration emission value a
h
= m/s
2
<2.5 <2.5
Uncertainty K = m/s
2
1.5 1.5
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
English (original instructions)
PLUNGE SAW
DWS520

DeWalt DWS520 Specifications

General

Type	Track Saw
Blade Diameter	165 mm
Bevel Capacity	47°
No Load Speed	1750 - 4000 RPM
Depth of Cut at 90°	59 mm
Depth of Cut at 45°	44 mm
Weight	5.1 kg
Arbor Size	20 mm
Power Source	Corded
Voltage	230V
Motor Power	1300 W
