13
ENGLISH
TABLE 1: COMPOUND MITER CUT
(POSITION WOOD WITH BROAD FLAT SIDE ON THE TABLE AND THE NARROW EDGE AGAINST THE FENCE)
SET THIS MITER ANGLE ON SAW
SQUARE BOX
6-SIDED BOX
SET THIS BEVEL ANGLE ON SAW
8-SIDED BOX
ANGLE OF SIDE OF BOX (ANGLE A)
