6
ENGLISH
CROSSCUT MITRE SAW
DWS771, DWS777
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough product
development and innovation make
DeWALT
one of the most reliable
partners for professional power toolusers.
Technical Data
DWS771 DWS777
Voltage
V
AC
230 230
U.K. & Ireland only
V
AC
230 230/115
Type 2 2
XPS Yes Yes
Power input W 1550 1800/1600
Blade diameter mm 216 216
Blade bore mm 30 30
Max. blade speed min
-1
2600–5200 6300
Kerf width mm 2.6 2.6
Mitre (max. positions) left and right 50° 50°
Bevel (max. positions) left 48° 48°
Compound mitre bevel 45° 45°
mitre 45° 45°
Capacities
cross-cut 90°
mm 60 x 270 60 x 270
mitre 45°
mm 60 x 190 60 x 190
mitre 48°
mm 60 x 180 60 x 180
bevel 45°
mm 48 x 270 48 x 270
bevel 48°
mm 45 x 270 45 x 270
Overall dimensions mm 460 x 560 x 430 460 x 560 x 430
Weight kg 15.5 15.5
Noise values and/or vibration values (triax vector sum) according to EN62841:
L
PA
(sound pressure)
dB(A) 93 96
L
WA
(acoustic power)
dB(A) 102 107
K (acoustic power
uncertainty)
dB(A) 3 3
The vibration and/or noise emission level given in this information sheet has
been measured in accordance with a standardised test given in EN62841
and may be used to compare one tool with another. It may be used for a
preliminary assessment ofexposure.

WARNING: The declared vibration and/or noise emission level
represents the main applications of the tool. However if the tool is
used for different applications, with different accessories or poorly
maintained, the vibration and/or noise emission may differ. This may
significantly increase the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or noise should
also take into account the times when the tool is switched off or when
it is running but not actually doing the job. This may significantly
reduce the exposure level over the total workingperiod.
Identify additional safety measures to protect the operator from the
effects of vibration and/or noise such as: maintain the tool and the
accessories, keep the hands warm (relevant for vibration), organisation
of workpatterns.
EC-Declaration of Conformity
Machinery Directive
Cross-Cut Mitre Saw
DWS771, DWS777
DeWALT
declares that these products described under Technical Data are
in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN62841-1:2015/AC:2015;
EN62841-3-9:2015/AC:2016-09.
These products also comply with Directive 2014/30/EU and 2011/65/EU. For
more information, please contact
DeWALT
at the following address or refer
to the back of themanual.
The undersigned is responsible for compilation of the technical file and
makes this declaration on behalf of
DeWALT
.
Markus Rompel
Vice President of Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
20.09.2019
WARNING: To reduce the risk of injury, read the instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word.
Please read the manual and pay attention to thesesymbols.

DANGER: Indicates an imminently hazardous situation which, if not
avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderateinjury.
NOTICE: Indicates a practice not related to personal injury which,
if not avoided, may result in propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
General Power Tool Safety Warnings

WARNING: Read all safety warnings, instructions, illustrations
and specifications provided with this power tool. Failure to follow
all instructions listed below may result in electric shock, fire and/or
seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE.
The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark areas
inviteaccidents.
English (original instructions)
