ENGLISH
32
MITRE SAW
DWS780
Congratulations!
You have chosen a DEWALT tool. Years of experience, thorough
product development and innovation make DEWALT one of the most
reliable partners for professional power tool users.
Technical Data
DWS780
Voltage V
AC
230
U.K. & Ireland V
AC
230/115
Type 10
Power input W 1675
Blade diameter mm 305
Blade bore mm 30
Blade body thickness mm 1.8
Max. blade speed min
-1
1900–3800
U.K. & Ireland min
-1
1600–3600
Max. cross-cut capacity 90° mm 349
Max. mitre capacity 45° mm 244
Max. depth of cut 90° mm 112
Max. depth of bevel cross-cut 45° mm 56
Mitre (max. positions) left 50°
right 60°
Bevel (max. positions) left 49°
right 49°
0° mitre
Resulting width at max. height 112 mm mm 299
Resulting width at max. height 110 mm mm 303
Resulting height at max. width 345 mm mm 76
45° mitre left
Resulting width at max. height 112 mm mm 200
Resulting height at max. width 244 mm mm 76
45° mitre right
Resulting width at max. height 112 mm mm 211
Resulting height at max. width 244 mm mm 76
45° bevel left
Resulting width at max. height 63 mm mm 268
Resulting height at max. width 345 mm mm 44
45° bevel right
Resulting width at max. height 62 mm mm 193
Resulting height at max. width 345 mm mm 28
Automatic blade brake time s < 10
Weight kg 25.4
L
PA
(sound pressure) dB(A)
93
K
PA
(sound pressure uncertainty) dB(A)
3.0
L
WA
(sound power) dB(A)
100
K
WA
(sound power uncertainty) dB(A)
3.0
Vibration total values (triax vector sum) determined according to EN 61029:
Vibration emission value a
h
a
h
=
m/s²
<
2.5
Uncertainty K = m/s²
1.5
The vibration emission level given in this information sheet has been
measured in accordance with a standardised test given in EN 61029
and may be used to compare one tool with another. It may be used for
a preliminary assessment of exposure.
WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure level
over the total working period.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job. This
may significantly reduce the exposure level over the total
working period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and
the accessories, keep the hands warm, organisation of
work patterns.
Fuses
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
U.K. & Ireland 115 V tools 16 Amperes, mains
Defi nitions: Safety Guidelines
The definitions below describe the level of severity for each signal word.
Please read the manual and pay attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided, will result in death
or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal
injury which, if not avoided, may result in property
damage.
Denotes risk of electric shock.
Denotes risk of fire.
EC-Declaration of Conformity
MACHINERY DIRECTIVE
DWS780
DEWALT declares that these products described under Technical Data
are in compliance with:
2006/42/EC, EN 61029-1, EN 61029-2-9.
These products also comply with Directive 2004/108/EC and
2011/65/EU. For more information, please contact DEWALT at the
following address or refer to the back of the manual.
The undersigned is responsible for compilation of the technical file and
makes this declaration on behalf of DEWALT.
Horst Grossmann
Vice President Engineering and
Product Development
DEWALT, Richard-Klinger-Strasse 11,
D-65510, Idstein, Germany
01.11.2011
