DeWalt DXGNP30E - Technical Specifications; Generator Model Specs

22
SPECIFICATIONS
Generator Model DXGNP30E DXGNP35E DXGNP65E DXGNP85E DXGNP853E
Type
Displacement 212 223 419 458 458
Bore×stroke(mm) 70x55 70x58 90x66 92x69 92x69
Compression ratio 8.7:1 8.7:1 8.5:1 8.5:1 8.5:1
Starting system
Ignition syatem
Fuel oil tank volume(L) 20 20 28 28 28
Lube oil capacity(L) 0.55 0.55 1.1 1.1 1.1
Max power(kW) 3 3.5 6.5 8.5 8.5
Rated power (kW) 2.7 3.2 6 8 8
Rated voltage(V) 230 230 230 230 400/230
Rated frequency(Hz) 50 50 50 50 50
Power factor 1 1 1 1 1
Insulation grade F F F F F
Perfomance grade G1 G1 G1 G1 G1
Net weight(kg) 49/52 54/57 81/855 92/96 95/99
Dimensions 590×460×510 590×460×510 696×553×628 696×553×628 696×553×628
Generator
Engine
T.C.I
Recoil start and electric start Recoil start
Single cyclinder,four stroke, horizontal shaft output,the gasoline engine
