DeWalt DXPW001E - Avoiding Surface Damage; Surface Cleaning Precautions; EC Declaration of Conformity; Warranty Information

EN
16
ENGLISH
EN - 10
T echnical Data Unit
DXPW 001 E DXPW 002 E DXPW 003 E
Flow rate l/min
9 8,8 10,5
Maximum ow rate l/min
- - -
P ressure MPa
11,5 14 12
Maximum pressure MPa
13 15 13
Power kW
2,3 2,7 2,9
Maximum inlet temperature °C
60 60 60
Maximum inlet pressure MPa
1 1 1
Gun repulsive force at maximum pressure N
21,40 21,80 30,30
Pump oil type kg
0.08 ISO VG 100 0.08 ISO VG 100 0.13 SAE 15W40
Protection class -
I / I / I /
Motor insulation
Class F F F
Motor protection -
IPX5 IPX5 IPX5
Voltage V/Hz
230/50 1~ 230/50 1~ 230/50 1~
Maximum permitted electrical system impedance
Ω - 0,153 0,153
Sound pressure level L
PA
(EN 60704-1)(K = 2,5 dB(A))
dB (A) 85,49 84,64 85,1
Sound power level L
WA
(EN 60704-1)(K = 2,5 dB(A))
dB (A) 99 99 99
Appliance vibration (K = 1 m/s
2
): m/s
2
<2,5 <2,5 <2,5
Weight kg
23 27 27
Subject to technical modification!
Technical Data
