A. Sliding Handles
B. Handle Grip
C. Storage Support
D. Regulated Pressure Gauge
E. Quick Connects
F. Regulator
G. Safety Valve
Voltage: Single 120V
Minimum branch circuit requirement: 15 A
Fuse Type: Time delay
MODEL
D55146
WEIGHT
83 lbs. (37.65 kg)
HEIGHT
15.5" (393.7 mm)
WIDTH
23.0" (584.2 mm)
LENGTH
33.0" (838.2 mm)
AIR TANK CAPACITY
4.5 Gallon (17.0 liters)
APPROX CUT-IN PRESSURE
160 psi
APPROX. CUT-OUT PRESSURE
200 psi
SCFM @ 90 PSI
5.2 *
NOISE LEVEL
78 dBA +
*Tested per ISO 1217:1996
+Tested per ISO 3744:1994
H. Pressure Switch
I. Cord Wrap
J. Air Filter
K. Tank Pressure Gauge
L. Auto(I)/Off(O) Switch
M. Drain Valve
Noise Emission Values
Sound Pressure Level: LpA = 78.0 dBA re 20μPA
Uncertainty in the Sound Pressure Level: KpA = 3.0 dBA re 20μPA
Sound Power Level: LwA = 91.0 dBA re 1 pw
Uncertainty in the Sound Power Level: KwA = 3.0 dBA re 1 pw
The sum of the emission value and the uncertainty is the limit
below which there is a 95% confidence the value of a single tool
will lie below when the tool is new.
FIG. 1
E
B
A
F
L
H
I
D
K
C
J
M
G
