T1000
Model T1000 Cat. No. DDF211001P
8
TRIM ALONG DOTTED LINE, PLACE IN ENVELOPE, ADDRESS AS SHOWN AND AFFIX POSTAGE
#
☐ Check the correct answer
1 It is necessary to read the Operator’s Manual
prior to operating a D
EWALT low velocity tool.
☐ True ☐ False
2 When fastening into concrete, the base
material should be greater than the shank
penetration by at least:
☐ 1 time ☐ 2 times ☐ 3 times
3 When operating a powder actuated tool, your
hand should never be placed:
☐ around the tool body
☐ in front of the tool muzzle
☐ over the tool handle
4 To determine the suitability of a base
material, use the fastener as a center punch.
• Ifthefastenerisblunted,donotfasten;the
material is too:
☐ soft ☐ hard ☐ brittle
• Ifthefastenerpenetrateseasily,donot
fasten; the material is too:
☐ soft ☐ hard ☐ brittle
• Ifthematerialcracksorshatters,donot
fasten; the material is too:
☐ soft ☐ hard ☐ brittle
5 Unsafe applications for powder actuated tools
may be caused by which of the following?
☐ a soft base material
☐ improper powder load
☐ fastening too close to an unsupported edge
☐ a malfunctioning tool
☐ fastening into a spalled area
☐ fastening through a pre-existing hole
☐ all of the above
6 Which one of the following building materials
is not suitable as a receiving material (base
material) for powder actuated fasteners?
☐ sheet rock ☐ wood ☐ fiberglass
☐ sheet metal ☐ all of the above
7 When considering the safety of a particular
application, the operator must think about:
☐ the base material
☐ the powder load power level
☐ the operator’s safety
☐ the safety of bystanders and fellow workers
☐ all of the above
8 The proper loading procedure is: insert fastener
first, powder load second. The fastener should
always be placed in the tool prior to the load.
☐ True ☐ False
9 Which one of the following materials
is usually suitable for powder actuated
fastenings?
☐ poured concrete ☐ hollow tile
☐ surface hardened steel ☐ glazed brick
10 In concrete, a fastener should be driven no
closer to an unsupported edge than:
☐ 1/2” ☐ 1-1/2” ☐ 3”
11 Fishhooking is a condition which can occur
when a powder actuated fastener strikes a
piece of hard aggregate or very hard concrete,
bends and comes out of the work surface. A
fishhook can cause a serious injury or death.
☐ True ☐ False
12 Placing a hand over the muzzle bushing of a
loaded tool can result in serious injury from
piston overdrive or an escaping fastener if
the tool is discharged accidentally.
☐ True ☐ False
13 Piston overdrive is caused by overpowering
of the tool or by discharging the tool against
a soft surface.
☐ True ☐ False
14 Malfunctioning tools cannot be used and
must be removed from service immediately.
☐ True ☐ False
15 After conducting a Center Punch Test,the best
way to check the base material is to set several
fasteners using the least powerful load.
☐ True ☐ False False
16 Eye protection and hearing protection should
not be worn by the operator and any necessary
bystanders when using the tool.
☐ True ☐ False
17 A powder actuated tool cannot be safely used in
an explosive or flammable atmosphere.
☐ True ☐ False
18 List the proper powder load level number
(1-6) next to each color listed.
Red ___ Brown ___ Green ___
Yellow ___ Gray ___ Purple ___
19 The weakest power level should be used
when making the first fastening.
☐ True ☐ False
20 You can fasten into welded areas of steel.
☐ True ☐ False
T1000
• Theproperprocedureifapowderloadfails
to ignite is to hold the tool against the work
surface and wait 30 seconds, then proceed
exactly as directed in the Operator’s Manual.
☐ True ☐ False
• D
EWALT powder loads for the T1000 are .22
caliber, “A” tapered, neck down, rim fire,
short crimped cartridges. No other powder
load may be used in this tool.
☐ True ☐ False
• OperatorsshouldnevercompresstheT1000
or any other powder actuated tool against
any part of their body.
☐ True ☐ False
• IfapistonbufferfortheT1000becomes
deformed, simply remove it, and use the tool
without the buffer?
☐ True ☐ False
Qualified Tool operaTor examinaTion
OPERATORS NAME COMPANY NAME
HOME ADDRESS COMPANY ADDRESS
AGE DATE OF BIRTH COMPANY PHONE
SIGNATURE DATE
LICENSE AND WARRANTY ACTIVATION
THE T1000 TOOL IS WARRANTED FOR 3 YEARS FROM DATE OF PURCHASE ON MANUFACTURERS DEFECTS.
I certify that I have read and understand the T1000 Tool Operating Instruction Manual and have taken the Operator’s exam. I
understand the importance of following all safety procedures and that failure to read, comprehend, and follow the detailed rules
and warnings regarding the safe operation of powder actuated tools can result in serious injury or death to the tool operator or
bystanders. I agree to conform to all the rules and regulations regarding the use of powder actuated tools. (Please print clearly)
THE SERIAL NUMBER ON MY TOOL IS:
PLEASE SEND MY TOOL LICENSE TO:
NAME
ADDRESS
CITY STATE ZIP PHONE
MAIL TO: Tool License Coordinator • DEWALT, Inc.• 2 Powers Lane, Brewster, NY 10509
