DeWalt XR DCH481 User Manual

24
ENGLISH
EC-Declaration of Conformity
Machinery Directive
Rotary Hammer
DCH481
DeWALT declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841-1:2015 +A11:2022,
EN IEC 62841-2-6:2020 +A11:2020.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact DeWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofDeWALT.
Markus Rompel
Vice-President Engineering, PTE-Europav
DeWALT, Richard-Klinger-Straße 11,
65510, Idstein, Germany
30.12.2022
DECLARATION OF CONFORMITY
THE SUPPLY OF MACHINERY (SAFETY)
REGULATIONS 2008
Rotary Hammer
DCH481
DeWALT declares that these products described under
Technical Data are in compliancewith:
The Supply of Machinery (Safety) Regulations, 2008, S.I.
2008/1597 (as amended),
EN62841-1:2015 +A11:2022, EN IEC 62841-2-6:2020 +A11:2020.
These products conform to the following UK Regulations:
Electromagnetic Compatibility Regulations, 2016, S.I.2016/1091
(as amended).
The Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations 2012, S.I.
2012/3032 (as amended).
For more information, please contact DeWALT at the following
address or refer to the back of the manual.
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
DCH481
Voltage V
DC
54
Type 2
No-load speed min
-1
540
No-load Impact rate bpm 3150
Single impact energy (EPTA 05/2009) J 6.1
Maximum drilling range in concrete mm 40
Optimum drilling range in concrete mm 16–30
Maximum core drilling range in concrete mm 45-100
Tool Holder SDS-MAX
Collar diameter mm 76
Battery Type Li-Ion
Weight (without battery pack) kg 5.4
Noise and vibration total values (triax vector sum) according to
EN IEC 62841-2-6:
L
PA
(emission sound pressure level) dB(A) 98
L
WA
(sound power level) dB(A) 106
K (uncertainty for the given sound level) dB(A) 3
Drilling into concrete
Vibration emission value a
h, HD
= m/s² 9.1
Uncertainty K = m/s² 1.5
Chiselling
Vibration emission value a
h
, Cheq
= m/s² 8.1
Uncertainty K = m/s² 1.5
English (original instructions)
HEAVY-DUTY CORDLESS ROTARY HAMMER
DCH481
The vibration and/or noise emission level given in this information
sheet has been measured in accordance with a standardised test
given in EN62841 and may be used to compare one tool with
another. It may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However,
if the tool is used for different applications, with different
accessories or is poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase the
exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool is
switched off or when it is running but not actually doing the
job. This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm (relevant
for vibration), organisation of workpatterns.
