DeWalt XR DCH481 User Manual

33
ENGLISH
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.
1. Choose and install the appropriate chuck, adapter, and/or
bit onto to the tool. Refer to Bit and BitHolders.
2. Using the mode selector dial
5
, selectthe mode
appropriate to desired application. Refer to
OperationModes.
3. Adjust the side handle
3
asrequired.
4. Place the bit/chisel on the desiredlocation.
5. Depress the trigger switch
4
.
NOTE: Depending on your tool, depressing the trigger
switch activates a worklight
10
designed to illuminate the
immediate work surface. Refer to Description. The worklight
will automatically turn off 20 seconds after the trigger
switch isreleased.
Recommendations for Tool Operation
• When drilling, always apply pressure in a straight line with
the bit, but do not push hard enough to stall the motor or
deflect thebit. A smooth even flow of material indicates the
proper drillingrate.
• Your hammer can be used for dry diamond drilling into
masonry up to 100 mm. For diamond drilling above this
diameter in masonry and regular large diameter diamond
drilling in masonry and concrete, we advise the use of
a dedicated diamond core drill. Follow the core bit or
manufacturer’s recommendations for using the accessory.
NOTE: Always use core bits with integral centredrill systems
and ensure the RPM (speed) of the hammer does not
exceed the maximum rated RPM of the diamondcore.
- Insert the centredrill into its holder in the centre of the
corebit.
- Remove and unplug themachine.
- Remove the centredrill from itsholder.
- Plug the machine in and insert the core bit into
theworkpiece.

WARNING:
• Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol, etc.).
• Do not mix or stir inflammable liquids
labelledaccordingly.
MAINTENANCE
Your DeWALT power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories

WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Various types of SDS-Max drill bits and chisels are available as
anoption. Accessories and attachments used must be regularly
lubricated around the SDS-Maxfitment.
Consult your dealer for further information on the compatibility
of appropriateaccessories.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails to
produce sufficient power on jobs which were easily done before.
At the end of its technical life, discard it with due care for our
environment:
• Run the battery pack down completely, then remove it from
thetool.
