13
ENGLISH
Worklight (Fig.F)
There is aworklight
8
located on the foot of the tool. The
worklight is activated when the trigger switch is depressed.
When the trigger is released, the worklight will stay illuminated
for up to 20seconds.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
Performing an Application (Fig.A)

WARNING: To reduce the risk of personal injury,
ALWAYS ensure workpiece is anchored or clampedfirmly.

WARNING: Always wait until the motor has come to
acomplete standstill before changing the direction
ofrotation.
Prior to performing work:
• Set the speed selector
7
. Refer to SpeedSelection.
• Install the appropriate bit or accessory into the chuck. Refer
to Installing aBit or Accessory into aKeylessChuck.

WARNING:
• Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol,etc.).
• Do not mix or stir flammable liquids
labeledaccordingly.
Screwdriving
Your tool has aclutch with adjustable torque for driving and
removing awide array of fastener shapes and sizes. The numbers
on the mode selection collar
6
are used to set atorque range
for screwdriving. The higher the number on the collar, the higher
the torque and the larger the fastener which can bedriven.
1. Turn the mode selection collar
6
to the desiredposition.
Refer to Mode Selection.
2. Pull the trigger switch applying pressure in astraight line
with the bit until the fastener is seated at the desired depth
in theworkpiece.
Recommendations for Screwdriving
• Start with lower torque settings, then advance to higher
torque settings to avoid damage to the workpiece
orfastener.
• Make some practice runs in scrap or on unseen areas of the
workpiece to determine the proper position of the mode
selectioncollar.
Drilling
1. Turn the mode selection collar
6
to the drillsymbol. Refer
to ModeSelection.
2. Place drill bit in contact with theworkpiece.
NOTE: Use sharp drill bitonly.
3. Pull the trigger applying pressure in astraight line with the
bit until it reaches the desireddepth.

WARNING: Drill may stall if overloaded causing asudden
twist. Always expect the stall. Grip the drill firmly to control
the twisting action and avoidinjury.
4. Keep the motor running when pulling the bit back out of
adrilled hole to preventjamming.
Recommendations for Drilling
• When drilling, always apply pressure in astraight line with
the bit, but do not push hard enough to stall the motor or
deflect thebit.
• IF THE DRILL STALLS:
 RELEASE TRIGGER SWITCH IMMEDIATELY, remove
drill bit from work, and determine cause ofstalling.
- DO NOT DEPRESS TRIGGER SWITCH ON AND OFF
IN AN ATTEMPT TO START ASTALLED DRILL—THIS
CAN DAMAGE THEDRILL.
- To minimize stalling or breaking through the material,
reduce pressure on drill and ease the bit through the last
fractional part of thehole.
• Large holes (7.9 mm to 12.7 mm) in steel can be made
easier if apilot hole (4 mm to 4.8mm) is drilledfirst.
• If drilling thin material or material that is prone to splinter,
use awood “back-up” block to prevent damage to
theworkpiece.
MAINTENANCE
Your DEWALT power tool has been designed to operate
over along period of time with aminimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use acloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories

WARNING: Since accessories, other than those offered
by D
EWALT , have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only D
EWALT recommended
accessories should be used with thisproduct.

DeWalt XR Li-Ion DCD701 Specifications

General

Voltage	12V
Max Torque	57.5 Nm
Speed Settings	2
Chuck Size	10 mm
Battery Type	Li-Ion
No Load Speed (RPM)	0-425/0-1500 RPM
Chuck Size (Alternate Unit)	3/8 inch
Weight (Alternate Unit)	2 lbs
