DeWalt XR Li-Ion DCD701 User Manual

ENGLISH
5
and the accessories, keep the hands warm, organisation of
workpatterns.
EC-Declaration of Conformity
Machinery Directive
Sub-Compact Drill/Driver
DCD701
DEWALT declares that these products described under Technical
Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-1:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact D
EW A L T a t
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofD
EW A L T .
Markus Rompel
Vice-President Engineering, PTE-Europa
D
EWALT , Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
06.12.2018
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.

WARNING: Indicates apotentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.

CAUTION: Indicates apotentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates apractice not related to
personal injury which, if not avoided, may result in
propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
Congratulations!
You have chosen aDEWALT tool. Years of experience, thorough
product development and innovation make D
EWALT one of the
most reliable partners for professional power toolusers.
Technical Data
DCD701
Voltage V
DC
12
Type 1
Battery type Li-Ion
Power output W 250
No-load speed
1st gear
2nd gear
min
-1
min
-1
0–425
0–1500
Max. Torque (hard/soft) Nm 57.5/25.5
Chuck capacity mm 10
Maximum
drilling capacity
Wood
Metal
mm
mm
20
10
Weight (without battery pack) kg 0.87
Noise values and vibration values (triax vector sum) according to EN62841-2-1:
L
PA
(emission sound pressure level) dB(A) 72
L
WA
(sound power level) dB(A) 83
K (uncertainty for the given sound level) dB(A) 3
Drilling into metal
Vibration emission value a
h,D
= m/s
2
2.5
Uncertainty K = m/s
2
1.5
Screwdriving
Vibration emission value a
h
= m/s
2
< 2.5
Uncertainty K = m/s
2
1.5
The vibration emission level given in this information sheet has
been measured in accordance with astandardised test given in
EN62841 and may be used to compare one tool with another. It
may be used for apreliminary assessment ofexposure.

WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure
level over the total workingperiod.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool
SUBCOMPACT DRILL/DRIVER
DCD701

DeWalt XR Li-Ion DCD701 Specifications

General

Voltage	12V
Max Torque	57.5 Nm
Speed Settings	2
Chuck Size	10 mm
Battery Type	Li-Ion
No Load Speed (RPM)	0-425/0-1500 RPM
Chuck Size (Alternate Unit)	3/8 inch
Weight (Alternate Unit)	2 lbs
