Intended Use
Your DCS367 cordless reciprocating saws have been designed
for professional sawing of wood, metal and tubes. The
compact design permits cutting extremely close to the edge of
difficultareas.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
These reciprocating saws are professional power tools.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
WARNING: Use only
battery packs andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. B, C)
NOTE: Make sure your battery pack is fullycharged.
To Install the Battery Pack into the Tool
Handle
1. Align the battery pack
6
with the rails inside the tool’s
handle (Fig. C).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the battery release button
7
and firmly pull the
battery pack out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some
battery packs include a fuel gauge which consists
of three green LED lights that indicate the level of charge
remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge button.
A combination of the three green LED lights will illuminate
designating the level of charge left. When the level of charge
in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Variable Speed Trigger Switch (Fig. D)
Lock-off Button and Trigger switch
Your saw is equipped with a lock-off button
2
.
To lock the trigger switch, press the lock-off button as shown
in FigureD. Always lock the trigger switch
1
when carrying or
storing the tool to eliminate unintentional starting. The lock-
off button is colored red to indicate when the switch is in its
unlocked position.
To unlock the trigger switch, press the lock-off button as
shown in FigureD. Pull the trigger switch to turn the motor ON.
Releasing the trigger switch turns the motor OFF.
WARNING: This tool has no provision to lock the switch
in the ON position, and should never be locked ON by any
other means.
The variable speed trigger switch will give you added versatility.
The further the trigger is depressed the higher the speed of
thesaw.
CAUTION: Use of very slow speed is recommended only
for beginning a cut. Prolonged use at very slow speed may
damage your saw.
Worklight (Fig. A)
There is a worklight
9
located on the end of the tool near the
shoe. The worklight is activated when the trigger switch is
depressed. When the trigger is released, the worklight will stay
illuminated for up to 20 seconds.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as a flashlight.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Blade Installation and Removal
(Fig. A, E, F, I)
Different blade lengths are available. Use the appropriate blade
for the application. The blade should be longer than 90 mm and
should extend past the shoe and the thickness of the workpiece
during the cut. Do not use jigsaw blades with this tool.
WARNING: Cut hazard. Blade breakage may occur if the
blade does not extend past the shoe and the workpiece
To Next Page
