12
ENGLISH
during the cut (Fig.E). Increased risk of personal injury, as
well as damage to the shoe and workpiece may result.
To install blade into saw
1. Pull blade clamp release lever
3
up (Fig.A).
2. Insert blade shank from the front.
3. Push blade clamp release lever down.
NOTE: The blade can be installed in four positions as shown
in FigureF. The blade can be installed upside-down for flush
cutting. Refer to FigureJ.
To Remove blade from saw
CAUTION: Burn hazard. Do not touch the blade
immediately after use. Contact with the blade may result
in personal injury.
1. Open up blade clamp release lever.
2. Remove blade.
Proper Hand Position (Fig. H)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a sudden
reaction.
Proper hand position requires one hand on the hand grip
5
,
with the other hand on the main handle
8
.
Cutting with Blade in Horizontal Position
(Fig. G)
Your reciprocating saw is equipped with a horizontal blade
clamp. Installing a blade in the horizontal orientation allows
cutting close to floors, walls or ceilings where limited clearance
is available. Ensure that the shoe is pressed against the work
piece to avoid kickback.
Cutting (Fig. I–K)
WARNING: Always use eye protection. All users and
bystanders must wear approved eye protection.
WARNING: Exercise extra caution when cutting towards
operator. Always hold saw firmly with both hands
whilecutting.
Before cutting any type of material, be sure it is firmly anchored
or clamped to prevent slipping. Place blade lightly against
work to be cut, switch on saw motor and allow it to obtain
maximum speed before applying pressure. Whenever possible,
the saw shoe must be held firmly against the material being
cut (Fig.I). This will prevent the saw from jumping or vibrating
and minimise blade breakage. Any cuts that put pressure on the
blade such as angle or scroll cuts increase potential for vibration,
kickback, and blade breakage.
WARNING: Use extra caution when cutting overhead and
pay particular attention to overhead wires that may be
hidden from view. Anticipate the path of falling branches
and debris ahead of time.
WARNING: Inspect work site for hidden gas pipes, water
pipes, or electrical wires before making blind or plunge
cuts. Failure to do so may result in explosion, property
damage, electric shock, and/or serious personal injury.
Flush-To Cutting (Fig. I)
The compact design of the saw motor housing and spindle
housing permits extremely close cutting to floors, corners and
other difficult areas.
Pocket/plunge Cutting – Wood Only (Fig. J)
The initial step in pocket cutting is to measure the surface area
to be cut and mark clearly with a pencil, chalk or scriber. Use
the appropriate blade for the application. The blade should
be longer than 90mm and should extend past the shoe and
the thickness of the workpiece during the cut. Insert blade in
bladeclamp.
Next, tip the saw backward until the back edge of the shoe
is resting on the work surface and the blade clears the work
surface (position 1, Fig.J). Now switch motor on, and allow
saw to come up to speed. Grip saw firmly with both hands and
begin a slow, deliberate upward swing with the handle of the
saw, keeping the bottom of the shoe firmly in contact with
the workpiece (position 2, Fig.J). Blade will begin to feed into
material. Always be sure blade is completely through material
before continuing with pocket cut.
NOTE: In areas where blade visibility is limited, use the edge
of the saw shoe as a guide. Lines for any given cut should be
extended beyond edge of cut to be made.
Metal Cutting (Fig. K)
Your saw has different metal cutting capacities depending upon
type of blade used and the metal to be cut. Use a finer blade for
ferrous metals and a coarse blade for non-ferrous materials. In
thin gauge sheet metals it is best to clamp wood to both sides
of sheet. This will ensure a clean cut without excess vibration or
tearing of metal. Always remember not to force cutting blade as
this reduces blade life and causes costly blade breakage.
NOTE: It is generally recommended that when cutting metals
you should spread a thin film of oil or other lubricant along
the line ahead of the saw cut for easier operation and longer
bladelife.
MAINTENANCE
Your
power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
