Dewenwils HIDT12W - Installing; Installation Guidelines

Note: This switch can not be used if there is no neutral wire (usually white)
in the electrical box.
To avoid fire or electrical shock, make sure the power is off before wiring.
If you are unsure or uncomfortable with installation, contact a licensed
electrician.
Installing:
PART DESCRIPTION QUANTITY
In-wall Digital Timer 1
Screwless Wall Plate 2
Wall Box Screw 2
Wire Cup
Figure 1
4
A
B
C
D
02
