STEP 05: POWER ON
Turn on the main (Master) switch to get the power back, the light will turn
on automatically at dusk and off at dawn.
The lamp structure is described as following picture:
MOUNTING
BRACKET
WIRE
CONNECTORS
BLACK LIVE
WIRE
MOUNTING
SCREWS
BULB
(not included)
GROUND WIRE
WHITE NEUTRAL
WIRE
CLASS
SHADES
03
(1)Turn on the light, wait 30 seconds for the sensor to warm up, then select
one function.
(2)Unscrew the top knob and top cover, then you can adjust different modes,
sensitivity and delay time. Reinstall the top knob and cover after completing
the setting to ensure waterproofing reliability, as shown in Figure 1~4.
Operation description
