06
Flathead Screwdriver
not included)
oPC Aut Aut o+
Time
Low
Sens
Level
+
-
+
-
+
-
Slide Switch (Set to AUTO)
Detail A View
Fig.6
4. AUTO+ MODE: Set the slide switch to AUTO+.The fixture will stay OFF
at daytime and stay low-level brightness (0%-50% brightness to be manually
adjusted)at night if no motion is detected within 20-180 seconds，and
automatically adjust the brightness to 100% when human body activity
is sensed at night. It returns to the preset low-level brightness again
when the person leaves or remains stationary for 20-180 seconds
(according to the time you set). The factory preset time is 60s and the
brightness is 100%.
LOW LEVEL - This function is out of work in AUTO mode.
TIME - Adjust Lighting Time: Adjust the “Time” knob with a flat head
screwdriver (Not Included). Turn clockwise to increase the lighting time,
and counterclockwise to decrease the lighting time. For every 1/4 clockwise
rotation, the lighting time increases by 60 seconds. The maximum is 180
seconds.
