Page 2 / 26 Dexin Digital Technology Corp. Ltd.
NDS3536S Encoder Modulator ISDB-T User Manual
1.3 Specifications
Input
8/16/24 HDMI inputs for option
1 ASI in for re-mux
1 USB Player input for re-mux
128 IP input over UDP and RTP, GE port, RJ45
Video
Resolution
Input
1920×1080_60P, 1920×1080_60i,
1920×1080_50P, 1920×1080_50i,
1280×720_60P, 1280×720_50P,
720×576_50i,720×480_60i,
Output
1920×1080_30P, 1920×1080_25P,
1280×720_30P, 1280×720_25P,
720×576_25P,720×480_30P,
Encoding
MPEG-4 AVC/H.264
Bit-rate
1Mbps~13Mbps each channel
Rate Control
CBR/VBR
GOP Structure
IP…P (P Frame adjustment, without B Frame )
Audio
Encoding
MPEG-1 Layer 2, LC-AAC, HE-AAC and AC3 Pass through
Sampling rate
48KHz
Resolution
24-bit
Audio Gain
0-255 Adjustable
MPEG-1 Layer 2
Bit-rate
48/56/64/80/96/112/128/160/192/224/256/320/384 kbps
LC-AAC Bit-rate
48/56/64/80/96/112/128/160/192/224/256/320/384 kbps
HE-AAC Bit-rate
48/56/64/80/96/112/128 kbps
Multiplexing
Maximum PID
Remapping
255 input per channel
Function
PID remapping ( automatically or manually)
Accurate PCR adjusting
Generate PSI/ SI table automatically
Modulation
ISDB-T
Standard
ARIB STD-B31
Bandwidth
6M
Constellation
QPSK, 16QAM, 64QAM
Guard Interval
1/32, 1/16, 1/8, 1/4
Transmission
Mode
2K, 4K, 8K
Code rate
1/2, 2/3, 3/4, 5/6, 7/8
MER
≥40dB
RF frequency
50~960MHz, 1KHz step
RF out
16 non-adjacent carriers output (maximum
bandwidth 192MHz)
RF output level
-20dBm~+3dBm, 0.1dB stepping
