NDS3536S Encoder Modulator ISDB-T User Manual
1
Power supply and Grounding Pole
2
Power Indicator
3
ASI out (Optional)
4
ASI in
5
HDMI inputs
6
DATA: IP input and output port(GE)
7
NMS (Network management port)
8
USB Port(TS playing)
9
RF test and RF out port
