NDS3244S Multi-Channel Encoder User Manual
12
Figure-5
Figure-6
Select to configure logo, caption or QRcode
Select program1-8 to apply the logo insertion, or
you can select “all” to apply all programs
Click here to confirm the LOGO you selected
Browse and select
the Logo which has
been created
Put your logo everywhere
Enter your text
here
Put your caption anywhere
Select the text color and
background color
Set when to show caption. So do
Logo and QRCode.
