Dexing NDS3508B - SPTS Program Selection

NDS3508B Tuner to IP Gateway User’s Manual
11
Figure-7
Parameter → SPTS Select:
From the menu on left side of the webpage, clicking “SPTS Select”, it displays the interface
where users can choose 16 DVB-S/S2/S2X Tuner input and 2 ASI Input programs to output
from IP (max 512 SPTS). (Figure-8)
Figure-8
Configure ‘Input Area’ and ‘Output Area’ with buttons in ‘Operation Area’. Instructions are as
below:
: To filter/not filter the source CA information
: To enable/disable the PID remapping
To refresh the input program information
Input Area
Output Area
Operation Area
